Calibrating The Compass; Hdmi Settings; Advanced Dual Operator Mode - dji MATRICE 350 RTK User Manual

MATRICE 350 RTK User Manual

Calibrating the Compass

The compass may need to be calibrated after the remote controller is used in areas with
electromagnetic interference. A warning prompt will appear if the compass of the remote
controller requires calibration. Tap the warning prompt to start calibration. In other cases,
follow the steps below to calibrate the remote controller.
1. Enter the home screen.
2. Open Settings, swipe up, and select Compass.
3. Follow the diagram on the screen to calibrate the remote controller.
4. The user will receive a prompt when the calibration is successful.
• If the remote controller compass is working normally, "Calibration Success" will
be prompted after entering the calibration view. It is not necessary to perform the
calibration.

HDMI Settings

The touchscreen can be shared with a display screen via an HDMI cable. The resolution can be
set in Settings < Display < Advanced < HDMI.

Advanced Dual Operator Mode

M350 RTK aircraft support Advanced Dual Operator mode that allows two pilots to operate an
aircraft simultaneously remote controllers A and B. In this mode, both remote controllers have
equal control of the aircraft. The roles of both remote controllers operating the aircraft are not
assigned in advance. Instead, either pilot may gain control of the aircraft or the gimbal camera
as needed, allowing for more flexibility during the operation.
Control over the aircraft is independent of control over the gimbal camera. When a remote
controller gains control of the aircraft or the gimbal camera, the user can use the controller to
operate the aircraft or control the movement of the gimbal camera respectively.
Setting the Advanced Dual Operator Mode
Before using Advanced Dual Operator mode, the pilot needs to link the aircraft with both
remote controllers A and B. Follow the steps below to link the remote controllers.
1. Run the DJI Pilot 2 app.
2. Enter the homepage and tap Remote Controller A/B to activate linking. During linking, the
status LED of the remote controller will blink blue and the remote controller will beep.
Press and hold the power button on the aircraft for at least five seconds. The aircraft power
indicator will blink and beep twice to indicate that linking has started. When linking is
successful, the aircraft status indicators will blink green, the remote controller beep twice,
and the remote controller status LED turn solid green.
3. Thereafter, the aircraft control button on the remote controller with control of the aircraft
