iArmor
BEFORE INSTALLATION
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE
PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE
STARTING INSTALLATION. ASSISTANCE IS RECOMMEND-
ED. THANK YOU FOR CHOOSING OUR PRODUCT!
*ROCKER PANEL MOUNT
*NO DRILLING / TRIMMING REQUIRED
PART LIST
Driver Side Step Bar
iArmor
by APS
Driver Front Mounting
Bracket (DFM)
Driver Rear Mounting
Bracket (DRM)
Customer Support: info@iarmorauto.com
Torque Value
Fastener Size
Tightening Torque (ft-lbs)
6mm
8mm
10mm
12mm
14mm
Front
Passenger Front Mounting
Bracket (PFM)
Passenger Rear Mounting
Bracket (PRM)
1
®
PART#: IA-S926H
6-7
16-18
31-32
56-58
92-94
Passenger Side Step Bar
Rev. 20211201
Required
X
√
√
X
X
