iArmor
BEFORE INSTALLATION
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE
PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE
STARTING INSTALLATION. ASSISTANCE IS RECOMMEND-
ED. THANK YOU FOR CHOOSING OUR PRODUCT!
PART LIST
PART LIST
Driver Side Step Bar
Driver Side Step Bar
iArmor
by APS
X1
Driver Front Mounting
Bracket (DFM/DCM/PRM)
X1
Driver Center Mounting
Bracket (DFM/DCM/PRM)
Driver Rear Mounting
Bracket (PFM/PCM/DRM)
X1
*Driver Front Mounting Bracket , Driver Center Mounting and
Passenger Rear Mounting Bracket are Universal.
*Passenger Front Mounting Bracket , Passenger Center
Mounting Bracket and Driver Rear Bracket are Universal.
Customer Support: info@iarmorauto.com
Fastener Size
6mm
8mm
10mm
12mm
14mm
Front
Front
X1
Passenger Front
Mounting Bracket
(PFM/PCM/DRM)
X1
Passenger Center
Mounting Bracket
(PFM/PCM/DRM)
Passenger Rear
Mounting Bracket
(DFM/DCM/PRM)
X1
1
®
PART#: IA‐S159
Tightening Torque (ft-lbs)
6-7
16-18
31-32
56-58
92-94
Passenger Side Step Bar
Passenger Side Step Bar
Rev. 20201201
Advertisement
Table of Contents
Related Manuals for APS iArmor IA-S159
Summary of Contents for APS iArmor IA-S159
- Page 1 ® ® iArmor by APS PART#: IA‐S159 BEFORE INSTALLATION Fastener Size Tightening Torque (ft-lbs) REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE 16-18 PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE 10mm 31-32 STARTING INSTALLATION. ASSISTANCE IS RECOMMEND- 12mm 56-58 ED. THANK YOU FOR CHOOSING OUR PRODUCT!
- Page 2 iArmor ® M8 Large Flat Washer M8X1.25 Nylon Lock Nut M8X1.25-55mm Carriage Bolt Spacer U Bracket M8 Lock Washer M8X1.25 Hex Nut STEP 2 The instruction here is for your reference only. We strongly recommend the professional installer for best result. We are not responsible for any damage caused by the installation.
- Page 3 iArmor ® Front Rear (Fig 4) Driver Rear Mounting Bracket Location Pictured (Fig 3) Driver Center Mounting Bracket Location Pictured STEP 4 Once all (3) driver side mounting brackets are installed, select and attach the Driver Side Step Bar onto the Mounting Brackets with (3) U Brackets, (6) Spacers, (3) M8X1.25-55mm Carriage Bolts, (3) M8 Large Flat Washers, (3) M8 Lock Washers and (3) M8X1.25 Hex Nuts (Fig 5).
- Page 4 iArmor ® STEP 5 Attention Do periodic inspections to the installation to make sure Properly level and adjust the Step Bar and fully tighten all hard- that all hardware is secure and tight. ware. In order to protect your bars/boards, please use only mild soap/non-abrasive products for cleaning.
