® ® iArmor by APS PART#: IA-S002H Torque Value BEFORE INSTALLATION Fastener Size Tightening Torque (ft-lbs) Required REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE √ STARTING INSTALLATION. ASSISTANCE IS RECOMMEND- 16-18 ED. THANK YOU FOR CHOOSING OUR PRODUCT!
Page 3
iArmor ® STEP 2 The instruction here is for your reference only. We strongly recommend the professional installer for best result. We are not responsible for any damage caused by the installation. Along the inner body panel, identify the Driver Side Center and Rear Mounting Location (Fig 3 &...
Page 4
iArmor ® STEP 6 Hole size: 3/16” Once all (3) driver side mounting brackets are installed, select and attach the Driver Side Step Bar onto the Mounting Brackets (1) M10 Flat Washer with (3) U Brackets, (3) M8X1.25-55 Carriage Bolts, (3) M8 (1) M10 Lock Washer Large Flat Washers, (3) M8 Lock Washers and (3) M8X1.25 (1) M10X1.5 Hex Nut...
Page 5
iArmor ® Front NOTE: Torque all M8 X1.25-55 Car- riage Bolts to 16~18 Ib-ft. Don't over tighten, or the square bars will be damaged by the brackets M8 Large Flat Washer U Bracket M8 Lock washer M8X1.25 Hex Nut U Bracket M8X1.25-55mm Carriage Bolt Mounting Bracket...
