5203-TRM, 5205-TRM, 5206-TRM
Ballina
Trim Series
Operation & Maintenance Manual
Model Numbers
5203-TRM
Valve Trim with Hand Shower
5205-TRM
Shower Trim with Hand Shower
5206-TRM
Tub/Shower Trim with Hand Shower
Modifications
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-412HSB
30" slide bar in place of wall cradle on
hand shower units
-BBZ
Brushed bronze finish
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
Symmons Industries, Inc.
©2014 Symmons Industries, Inc.
Specifications
Tub/shower trim with hand shower and lever handle
includes wall connection, cradle for hand shower
mounting, in-line vacuum breaker, flexible metal
hose, non-diverter tub spout, 3 mode hand shower and
3 mode showerhead with standard 2.5 gpm (9.5 L/min)
flow restrictor. Shower trim with hand shower and lever
handle includes all of the above less non-diverter tub
spout. Valve trim with hand shower and lever handle
includes all of the above less non-diverter tub spout
and 3 mode showerhead. Components made from
metal and nonmetallic materials plated in standard
polished chrome finish.
Compliance
-ASME A112.18.1/CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
31 Brooks Drive
Braintree, MA 02184
www.symmons.com
gethelp@symmons.com
(800)796-6667
Fax: (800)961-9621
ZV-3065 REV A 09/18/14
