ROM E
MULATOR
Table 16 shows the location of the pins of the connector. All I/O signals on this connector are 3.3 V outputs
that are tolerant of 5V inputs.
Odd Pin Name
3.3 V PWR
ROMEMUCS_L
Document 91125E-UM100-R
P
INOUT

Table 16: ROM Emulator Pinout

Odd Pin Number
GND
AD18
AD17
AD14
AD13
AD8
AD9
AD11
OE_L
AD10
AD31
AD30
AD29
AD28
AD27
B roadc om C or por ati on
Even Pin
Number
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
BCM91125E
Even Pin Name
AD20
AD19
AD16
AD15
AD12
AD7
AD6
AD5
AD4
AD3
AD2
AD1
AD0
AD24
AD25
AD26
GND

ROM Emulator Pinout
