40-Pin Connector Definitions

MTQ-xx-B02

Pin Minimum and Maximum Voltage
Unless otherwise specified in the Pin Definitions table:
Serial Input Signals
Serial Output Signals
®
MultiConnect Dragonfly
Description
FCC Part 15 Class B
FCC Part 22H, 24E, 27, 90
CE Mark, RED (EU)
RCM
UKCA
UL 62368-1
cUL 62368-1
IEC 62368-1
PTCRB
AT&T/Verizon
Minimum High Voltage
2.0V
2.4V
TM
MTQ-L1G2D Device Guide
Maximum Low Voltage
0.8V
0.55
HARDWARE AND SPECIFICATIONS
Maximum Input
6.5V
--
9
