Chapter 4 – Getting Started
Installing a SIM Card on a DragonFly
Note:
When using the Dragonfly with a developer board, install the SIM card before mounting the Dragonfly on
the developer board.
To install the SIM card:
With the contact side facing down, align the notched edge as shown on the Dragonfly's SIM holder and slide
the SIM card completely into the SIM holder.
USB Cable Recommendations
To avoid enumeration or power issues:
Use a high-speed USB cable that is as short as possible.
Use a well-shielded cable with at least 24 AWG wire pair for power/ground and 28 AWG wire pair for data
lines.
If possible, use a USB port that connects directly to the motherboard rather than a USB port with added
cabling inside the computer chassis.
Use USB 3.0 ports if available. These ports are typically rated for more current.
The USB cable is available through MultiTech. The part number is CA-USB-A-MICRO-B-3.
Device Drivers
Install drivers on your computer before connecting the device.
To install drivers:
Use the
Connection Manager
OR
Refer to Linux or Windows driver installation information in the USB Driver Installation Guide. For
information, refer to
®
MultiConnect
Dragonfly
to install Windows drivers.
Documentation
TM
MTQ-L1G2D Device Guide
GETTING STARTED
15
