Rule Parts
24E
24E
27
27
Single Modular Approval. Output power listed is conducted. The antenna(s) used for this transmitter must be
installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter
evaluation procedures as documented in this filing. This device is to be used only for mobile and fixed application.
This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM integrators.
OEM integrators must ensure that end-users are not provided with the module installation instructions. OEM
integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure
compliance. The highest antenna gain including cable loss, must not exceed 8.51 dBi for Band 2 and Band 25, 5.5
dBi for Band 4, 6.91 dBi for Band 5 and Band 26, 9.91 dBi for Band 8, 9.7 dBi for Band 12, 9.91 dBi for Band 13 and
14, and 9.01 dBi for Band 7. This device supports 1.4 MHz, 3 MHz, 5 MHz, 10 MHz, 15MHz and 20 MHz bandwidth
modes for LTE Bands 2/4/25; 1.4 MHz, 3 MHz, 5 MHz, 10 MHz and 15MHz bandwidth modes for LTE Band 26; 1.4
MHz, 3 MHz, 5 MHz and 10 MHz bandwidth modes for LTE Bands 5/12; 5 MHz, 10 MHz, 15MHz and 20 MHz
bandwidth modes for LTE Bands 7; 1.4 MHz and 3 MHz for LTE Band 8; 5 MHz and 10 MHz bandwidth modes for
LTE Bands 14/13. This device contains functions that are not operational in U.S. Territories. This filing is only
applicable for U.S. operations.
®
MultiConnect Dragonfly
Frequency Range
1.8502-1.9098 GHz
1.8524-1.9076 GHz
2.5-2.57 GHz
2.5-2.57 GHz
TM
MTQ-L1G2D Device Guide
Power Output Frequency Tolerance Emission Designator
580 mW 2.5 ppm
398 mW 2.5 ppm
365 mW 2.5 ppm
291 mW 2.5 ppm
REGULATORY INFORMATION
243KG7W
4M14F9W
18M0G7D
18M0W7D
