GETTING STARTED

Communicating with the Device

Following are three options for communicating with the device.
Install USB drivers and plug into the micro USB connector. No need for a host board.
Access the device's USB interface via pins 6 and 7 of the 40-pin connector. Data pins 6 and 7 are in parallel
with the micro USB connector on the device. There is no connection to pins 6 and 7 on the developer board.
Establish serial communication using Multitech developer board MTUDK2. See the Universal Developer Kit
2.0 Developer Guide (PN S000610) for more information.

Powering Down Your Device

CAUTION: Failing to properly power down the device before removing power may corrupt your device's file
system.
To properly power down your device, use the following sequence or pull 3G_ONOFF signal low:
1. Issue the AT#SHDN command.
2. Wait 30 seconds.
3. Power off or disconnect power.
Note: If you send AT#SHDN and do not remove power AND the 3G_ONOFF line is high, the radio restarts after
60 seconds.

Device Reset (Pin 35)

Minimum pulse is 50 ms.
- If the reset line is held low for >50ms the radio is turned off.
- When the reset line is released, the radio is turned on.
