Summary of Contents for Multitech CommPlete MTPRI-HD23B
- Page 1 PRI Card MTPRI-HD23B & MTPRI-HD30B User Guide...
- Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc., to notify any person or organization of such revisions or changes.
-
Page 3: Federal Communications Commission Statement
Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 4: Canadian Limitations Notice
No repairs are to be made by you. Repairs are to be made only by MultiTech Systems or its licensees. Unauthorized repairs void registration and warranty. Manufacturer: Trade Name: Model Number: FCC Registration Number: Facility Interface Code: Service Order Code: Modular Jack (USOC): Service Center in USA: Canadian Limitations Notice... -
Page 5: Ringer Equivalence Number
Ringer Equivalence Number Notice: The ringer equivalence number (REN) asigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the ringer equivalence numbers of all the devices does not exceed 5. - Page 6 CommPlete Communications Server...
-
Page 7: Table Of Contents
Table of Contents 1 INTRODUCTION Introduction... 2 Product Description... 2 Features ... 2 Status LEDs... 2 Card Components... 4 8-Position DIP Switch... 4 Technical Specifications ... 6 2 INSTALLATION Introduction... 8 Safety Warnings ... 8 Pre-Installation Notes... 8 Installation Procedure... 9 3 SOLVING PROBLEMS Introduction... - Page 8 viii CommPlete Communications Server...
- Page 9 1 Introduction CommPlete Communications Server...
-
Page 10: Introduction
PRI Card User Guide Introduction The Multi-Tech PRI Card (MTPRI-HD23B for T1 or MTPRI-HD30B for E1) is a telecommunications interface card that provides CommPlete interconnectivity to Primary Rate ISDN (PRI) public switched telecommunications networks. The MTPRI-HD23 provides 23 B channels that provide 23 user sessions. - Page 11 LED Indicator Color PHYSICAL LINK Green DATA LINK Green RED ALARM YELLOW ALARM Yellow DATA CHANNEL Green CONTROL Green LED Indicator Color HOST FIFO Green HEART BEAT Green SYSTEM ERROR CHANNEL CLOCK Green CommPlete Communications Server Figure 1. PRI Card Front Panel Indication Lit - Indicates LEC circuit connection is active and signaling is correct.
-
Page 12: Card Components
PRI Card User Guide Card Components The 8-position DIP switch is located on the lower portion of the card and is used to set the operating modes of the card. The T1 line connector is a RJ48C connector located on lower back of the card and is used to connect to the T1 line facility. - Page 13 Equalization Control 4. See Note 1 Equalization Control 3. See Note 2 Equalization Control 2. See Note 2 Equalization Control 1. See Note 2 Note 1: Used with DIP-Switches 6 thru 8 for pulse equalization, line build-out (LBO), and equalizer gain limit settings.
-
Page 14: Technical Specifications
• ISDN Signaling (PRI) Standards • Standards Supported Intel 960 (16 MHz RISC processor) 4 Mb 512K bytes Flash 23B + D on MTPRI-HD23B and 30B + D on MTPRI-HD30B Simultaneous full duplex DMA (all channels) 10 LEDs T1 - B8ZS or AMI (programmable), E1 HDB3 T1 - ESF or D4 (programmable), E1 ESF T1 - 1.544 Mbps/E1 2.048 M +/- 200 bps... -
Page 15: Installation
Installation CommPlete Communications Server... -
Page 16: Introduction
• To reduce emissions, be sure to use blanking plates to cover empty slots in the CC9600 or CC2400 chassis. • When transporting the MTPRI-HD23B, wrap it in an anti-static bag (such as the original shipping packaging). When handling the board, observe anti-static procedures, such as the DOD-STD-1686 or equivalent . -
Page 17: Installation Procedure
Installation Procedure Typically the PRI card will be set up with the 8-position DIP switches all in the DOWN (Closed) position. This setting is for a T1 long haul configuration. If your configuration is different, set the 8-position DIP switches according to the T1 or E1 DIP Switch 5 thru 8 Configuration listing in Chapter 1 of this User Guide. - Page 18 PRI Card User Guide CommPlete Communications Server...
-
Page 19: Solving Problems
3 Solving Problems CommPlete Communications Server... -
Page 20: Introduction
7. Call your LEC representative and/or your ISDN service provider. Have the information that you recorded during hardware installation available. 8. Call Multi-Tech’s Tech Support department. Startup Self Test LED Patterns Each time the PRI card is reset (i.e., the CommPlete is powered on or the system reset is asserted) the PRI card firmware executes a series of startup self-test routines. -
Page 21: Problems Involving Heart Beat
Check the configuration of the PRI card with the PRISTATUS command at the controller. Contact your LEC representative or Multi-Tech's Technical Support Department if you continue to experience this alarm.
