DentalEZ Forest Installation Instructions

ROUTING DRAIN/SUCTION LINE
STEP 1: Remove covers. (FIG. 1)
STEP 2: Route and secure tubings together with zip tie. (FIG. 2)
CAUTION: Do not kink tubings with zip tie.
STEP 3: Make appropriate connection at utility center.
STEP 4: Reinstall covers.
STEP 5: Reinstall upholstery if originally removed.
DTE OREGON, INC.
DENTALEZ.COM
6200 NE Cherr y Drive, Hillsboro, OR 97124 USA
FIG. 1: REMOVE COVERS.
COVERS
FIG. 2: REAR UNIT DRAIN/SUCTION LINE.
(TF) F)
800 . 423 . 3555 (T) 503 . 640 . 3012 (
2.17.21 0097-305
R E A R PI VOT MOUN T
ALERT SYMBOL KEY
The safety notices associated with the following should be
given special attention when they appear in maintenance,
operating and emergency procedures in the guide.
WARNING indicates that the personal safety of the
patient, end user or technician could be compromised
by disregarding the WARNING. Not following instruc-
DRAIN LINE FROM
tions may result in an injury.
REAR PIVOT UNIT
CAUTION indicates that a particular procedure
or precaution must be followed to avoid system
irregularity or possible damage to the product.
NOTE indicates special information to improve the
ease of maintaining the product, or to clarify important
information.
Tools Required: 1/8" , 5/32" , 3/16" , 3/32" & 5/16" , 3mm, 8mm, and
10mm, Allen Hex Wrenches, 1/8" , 5/16" Allen Sockets with
Torque Wrench, 3/4" , 9/16" & 15/16" Wrench, Flathead Screw-
driver, and Nitrile Gloves.
NOTE: Chairs purchased before July of 2014 contain
metric screws, all chairs purchased after this date
contain standard screws. This kit contains a metric and
standard nut and bolt set to accommodate either chair.
Please check to make sure that you are using the
ZIP TIE correct tools and hardware for your chair before
TUBINGS
proceeding.
TOGETHER
NOTE: If rear pivot is already installed, proceed to page 3.
REAR PIVOT ASSISTANT'S OR CUSPIDOR
MOUNT 3900 CHAIR
STEP 1:
Position the chair's back in the fully up position and
the base in the fully down position. (FIG. 1)
STEP 2: Remove the 6 screws holding the upholstery in place
(Phillips screwdriver). Sit upholstery and hardware aside.
(FIG. 2)
503 . 693 . 9715
Rev. T 4 of 4
INSTALLATION
INSTRUCTIONS
CAUTION: To avoid electrostatic discharge (ESD)
damage to electronics, always wear grounded wrist
strap attached to a ground adapter (eg: Banana or
Grounding plug) when handling circuit boards, chair
controls, and cables or working in the area of electrical
circuits.
CAUTION: Field modifications that alter the electrical
and/or mechanical safety of Forest products conflict
with agency construction file requirements and are not
sanctioned by Forest.
NOTE: Installation Verification: Refer to Operator's
Guide or Service Manual on our website at Forest-
dental.com; perform all operations. If operations
performing as intended installation complete.
operations not performing as intended, review steps in
installation instructions to confirm correct installation or
call Forest Technical Support at 800-423-3555.
FIG.1: POSITION CHAIR
FIG. 2: REMOVE SEAT UPHOLSTERY
6
If
1 of 4
