- Page 1 Basic-Duo ® Chair Mounted Unit Installation, Operation and Care Manual DentalEZ Group 2500 Highway 31 South Bay Minette, AL 36507...
-
Page 2: Table Of Contents
Table of Contents Section I Introduction Section V Operation Introduction ............2 Delivery System ..........15 Specifications ............ 3 Handpiece ............16 Basic Components .......... 4 Foot Control ..........16 Vacuum Accessories ........17 Section II Pre-installation Air/Water Syringe ........17 Utility Service Center ........ -
Page 3: Introduction
aXcs ® Basic-Duo CMU Section I Introduction aXcs ® aXcs aXcs leave this manual in the doctor's office Clean Water Delivery Bottle Head Tray (Optional) Pivot Link Utility Service Center Chair Mount Instrument Hanger Foot Umbilical Control aXcs ® Delivery Head Utility Service Center Installation, Operation and Care Manual... -
Page 4: Specifications
Section I Introduction - 40 PSI Water Pressure Specifications Clean Water System Power Supply Reservoir Capacity - .75 to 1 liter • 115VAC, 50/60 Hz., as applicable • 220VAC, 50/60 Hz., as applicable - 38 lbs. Shipping Weight - 80 PSI Air Pressure SIDE VIEW 16"... -
Page 5: Basic Components
aXcs ® Section I Introduction Basic-Duo CMU Basic Components SHIPPING CONFIGURATION aXcs Delivery Head & NOTE Be aware that some cartons are shipped as fillers and may be empty (even if optional components Assembly Packing are ordered). Inserts aXcs Supplies —... -
Page 6: Section Ii Pre-Installation
Section II Pre-installation NOTE: For wood or metal floors, drill 5/32" Utility Service Center holes. For concrete, drill 1/4" holes and install plastic anchors. USC Carton Contents: — IMPORTANT NOTICE — • Utility Service Center (USC) DO NOT DISCARD the USC template •... -
Page 7: Electrical Contractor's Procedure
aXcs ® Basic-Duo CMU Section II Pre-installation NOTE: Pay close attention to the orientation of the Electrical Contractor's Procedure template to the chair. 3. Sweat the valve adaptors to the air and water stubs. — NOTICE — 4. Apply the appropriate thread sealant to the Electrical contractor's parts are not supplied. -
Page 8: Section Iii Installation
Section III Installation Delivery Head & Arm Assembly Countersink Bolts Carton Contents: • Delivery Head, Arm & Mounting Bracket Assembly • High-Volume Evacuator Valve • Saliva Ejector Valve • Solids Collector Traps (4) • Air/Water Syringe Bracket Hardware: 3. Install the brake handle cover. •... -
Page 9: Umbilical Connection
aXcs ® Basic-Duo CMU Section III Installation 4. Connect the yellow signal air line already on Umbilical Connection the poppet valve assembly to the 1/8" barb on the water stop valve assembly. Then secure 1. Using two #10 screws, attach the umbilical the yellow signal air line using a 1/8"... -
Page 10: Foot Control
Section III Installation (See the tubing diagram in the back of this manual.) Foot Control do not secure To Unit Foot Control Clip Ducting #10 Screw Hose Holes 8" L-Shaped Bracket 4" USC Base Position 7/16" (The ducting hose is left-hand threaded.) Power Cord Slot Base Pump Cover Recessed Area... -
Page 11: High-Volume Evacuator
aXcs ® Section III Installation Basic-Duo CMU 3. Connect the syringe air and water lines to the High-Volume Evacuator (HVE) appropriate male and female connectors on the delivery head chassis. 1. Connect the HVE Valve HVE valve to Water Line the 1/2"... -
Page 12: Fiber Optics (Optional)
Section III Installation Fiber Optics (Optional) Standard Receptacle Electrical (Fiber Optic) Power Pack Transformer Handpiece (Fiber Optic) Fiber Optic Control Assembly Electrical Lock Washers Screws Lead Alignment Tubing Clear Cover Tubings Wire Air Switch Leads Barb Fiber Optic Control Assembly aXcs ®... -
Page 13: Chipblower (Optional)
aXcs ® Section III Installation Basic-Duo CMU Chipblower (Optional) — WARNING — Chip- blower Other Options NOTE: Secure all connections Touch Pad Controller using the tubing clamps provided. aXcs Phillips-Head Screws Light Post Water Heater WET/DRY 6" Clear Toggle Valve Tubing 3"... -
Page 14: Section Iv Testing
Section IV Testing Delivery System — CAUTION — Before connecting handpieces, all air must be purged from the coolant water lines to Utility Service Center allow the system to function properly. 1. Turn on all services supplying the USC. 2. Open the air and water manual stop valves by 2. -
Page 15: Vacuum Accessories
aXcs ® Section IV Testing Basic-Duo CMU Flush Valve Air Pressure 1. Remove the handpiece from its holder. 1. Flip the toggle valve from WET to DRY at the foot control. 2. Activate the flush toggle valve. 2. To adjust the individual handpiece drive air 3. -
Page 16: Section V Operation
Section V Operation • An automatic CUT OFF, can be demonstrated Delivery System by placing tubing in the hanger and disabling operation for that position. The Basic-Duo CMU offers the following design • The handpiece features: holder angle • Operation of two handpieces and a syringe. can be adjusted •... -
Page 17: Handpiece
aXcs ® Section V Operation Basic-Duo CMU NOTE: When making necessar y air pressure adjust- Handpiece ments, refer to the air pressure gauge located at the front of the delivery head to check the approximate amount Coolant Water Spray of air pressure delivered to the handpiece. Coolant water spray to all the handpieces can be Flush System turned ON or OFF using the toggle switch located... -
Page 18: Vacuum Accessories
Section V Operation • Vacuum Accessories • Air/Water Syringe Air/Water Syringe High- volume Evacuator Saliva Ejector High Volume Evacuator NOTE: Air and water flows are factor y preset. Options • Lever Valve Fiber Optics Open Closed NOTE: When the foot control is released, the fiber optics light will stay on for approximately ten seconds to •... -
Page 19: Section Vi Care
aXcs ® Basic-Duo CMU Section VI Care Cleaning • • NOTE: After cleaning the saliva ejector, high-volume evacuator and solids collector, evacuate two cups of — CAUTION — Vac-U-Ez cleaning solution (one cup each) through the high- volume evacuator and saliva ejector to sanitize the system. •... -
Page 20: Section Vii User Service Information
Section VII User Service Information — WARNING — aXcs aXcs always Delivery Head l l i i l i ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○... -
Page 21: Arm System
aXcs ® Section VII User Service Information Basic-Duo CMU Arm System y l r y f i y f i y l r t f i Water Heater . y l " 8 o l l . e l s ' t y f i . - Page 22 Section VII User Service Information Handpiece (continued) d i l d i l p i l p i l d i l d i l e l t . y t l l i l t t y f i .
-
Page 23: Service Instruction
aXcs ® Section VII User Service Information Basic-Duo CMU Service Instruction Delivery Head Model Serial • Model Name Number Number • Model Number • Serial Number (Model and serial numbers found on the underside of the delivery head.) • Date of Installation Installation, Operation and Care Manual... -
Page 24: Section Viii Parts List/Diagrams
Section VIII Parts List/Diagrams Utility Service Center t l i t a l t l i t a l t a l t a l & t a l t a l t l i t a l aXcs ® Basic-Duo CMU... -
Page 25: Delivery Head
aXcs ® Section VIII Parts List/Diagrams Basic-Duo CMU Basic-Duo CMU Delivery Head c i t Optional Equipment e l l & t l i t s i e l t e l t t a l y t i e l t e l t e t I Installation, Operation and Care Manual... -
Page 26: Foot Control
Section VIII Parts List/Diagrams Arm Hardware t a l Foot Control aXcs ® Basic-Duo CMU... -
Page 27: Air/Water Syringe
aXcs ® Section VIII Parts List/Diagrams Basic-Duo CMU Air/Water Syringe r t r HVE Nozzle i r - i r - Saliva Ejector Nozzle i l a i l a i r - i r - Installation, Operation and Care Manual... -
Page 28: Product Support Services
Basic-Duo Chair Mounted Unit DentalEZ and its employees are proud of the products we provide in the dental community. We stand behind these products with a warranty against defects in material and workmanship as provided below. And, we have our own in- house repair facility to service our products. -
Page 29: Tubing Diagram
DELIVERY HEAD 1/8" Twin Wire Assembly, Curing Light/Scaler (Blue & Gray) Sterling Wire Assembly, Fiber Optics (Black & White) SYRINGE aXcs Basic-Duo CMU 1/8" Blue ® MASTER 1/4" Red 1/4" Red 1/8" Red 1/8" Red Tubing Diagram 1/8" Yellow 1/8" Yellow 1/4"... - Page 30 Chair Side 18-3/4" USC Base Suggested Electrical Outlet Location 15-18" + 1/32" 4-3/4" 5-11/16" 3-11/16" Ø 7/8" through 5-1/8" 1-1/8" 2-1/8" DRAIN Horizontal Center Line WATER 8-5/8" VACUUM + 1/32" 2" 1/2" 3 x Ø 5/8" through 7-9/16" Chair Center Line 4 x for #10-32 Anchors...
- Page 31 DELIVERY HEAD 1/8" Twin Wire Assembly, Curing Light/Scaler (Blue & Gray) Sterling Wire Assembly, Fiber Optics (Black & White) SYRINGE aXcs Basic-Duo CMU 1/8" Blue ® MASTER 1/4" Red 1/4" Red 1/8" Red 1/8" Red Tubing Diagram 1/8" Yellow 1/8" Yellow 1/4"...
- Page 32 2500 Highway 31 South Bay Minette Alabama 36507 Phone: 1-866-DTE-INFO Fax: (334) 937-0461 www.dentalez.com P. N. 2717-200A © Den-tal-ez, Inc. Printed in U. S. A. June, 2001...
