DentalEZ Star Titan Low-Speed Manual

DO NOT USE FOR ORAL SURGERY
Before operating the angle, carefully read and follow all of these instructions. Save these instructions for future
reference and observe all warnings and cautions.
INDICATIONS FOR USE
Used intraorally by trained dental professionals for drilling and preparation of dental cavities for restoration,
such as fillings, disking, cavity and crown preps, polishing, post and pin drilling and pin setting.
Caution: U.S. Federal law restricts this device to sale by or on the order of a licensed physician.
Under normal operating conditions, air is exhausted from the back of the head of this
WARNING
handpiece. If air is directed into an open soft tissue wound or beneath the mucosa or
dermis, injury to the patient could result from air emphysema of air embolism.
This angle has no internal air or water cooling capabilities. External water for cooling maybe
WARNING
required.

CONTENTS

FEATURES

FEATURES Rated for use with StarDental Motors and Attachments

ANGLE ADJUSTMENT

Auto Latch or Manual Bur Latch Contra Angles

ANGLE INSTALLATION

Smooth Running, Low Friction Performance

BUR INSTALLATION AND REMOVAL

Field Replaceable Cartridges and Transmission Gears
SAFETY INSTRUCTIONS
Easy Maintenance
Lubrication
Long Term Reliability

CARTRIDGE REPLACEMENT

Steam sterilization: 275° F (135° C) max.
Cleaning And Sterilization
Troubleshooting
Latch Replacement
135°C
Replacement Part Numbers
Sterilizable up to 135°C
Warranty
Motor 5K 5K 20K 20K
Accessories MTA 16:1 Endodontic MTA Torque Multiplier
Motor to Angle & MTA
Adapter
Ratio 1:1 16:1 1:1 4:1
Max Allowable RPM 5,000 300 20,000 5,000
ANGLE ADJUSTMENT
1. Loosen knurled ring enough to disengage splines.
2. Pull head assembly up; turn to desired position.
3. Carefully mesh the splines on the knuckle with the
splines of the head (see FIG.1).
4. Tighten knurled ring onto knuckle threads until snug.
ANGLE INSTALLATION
1. Thread angle onto the motor-to-angle adapter,
StarDentalTitan 3 Part #264073 or Titan T Part # 263970,
by hand. Seat completely.
NOTE: If angle does not seat on adapter, gears are not meshed
correctly. Remove angle; spin motor-to-angle adapter drive
gear and repeat Step 1.
2. Fit angle disconnect wrench,
StarDental Part #203048, furnished
with every angle, to mating
indentations on angle neck; tighten
securely(FIG. 3).
BUR INSTALLATION AND REMOVAL
NOTE: A concentric .0925" diameter (2.350 mm) groove & flat shank (ISO 1797-1. Type 1) bur should be used.
NOTE: Before installing bur, install motor to the motor-to-angle adapter; then install latch angle to
motor-to-angle adapter as described in Angle Installation.
INSTALLATION INTO THE AUTO LATCH ANGLE
1. Grasp angle firmly so that your thumb touches the cap; push on center of cap (FIG. 4).
FIG.4
Motor
MOTOR-TO-ANGLE ADAPTER
2. While continuing to hold cap down, insert a concentric .0925" diameter (2.350 mm) shank RA
(standard length for Contra Angle) bur the full length of chuck.
3. Rotate bur until fully engaged in latching mechanism and release thumb.
4. Tug on bur to verify proper seating and retention.
REMOVAL FROM AUTO LATCH
Grasp angle firmly so that your thumb touches the cap; push on center of cap and hold cap down while
pulling bur straight out.
INSTALLATION INTO THE MANUAL LATCH ANGLE
1. Open latch (FIG.5).
2. Insert a concentric .0925" diameter (2.350 mm) shank RA (standard
length for Contra Angle) bur the full length of chuck.
3. Engage latch lock firmly in latch of instrument.
4. Tug on bur to verify proper seating and retention.
REMOVAL FROM MANUAL LATCH
Open latch, pull bur straight out.
SAFETY INSTRUCTIONS
WARNING
TO MINIMIZE RISK OF SERIOUS INJURY:
• Always insert bur the full length of the chuck. If you attempt to extend it from the chuck, the bur may
dislodge during use and possibly injure you or your patient.
20K
• Use only recommended burs to prevent damage to the autochuck and in some cases to prevent burs from
Torque Multiplier &
improper or incorrect placement. An improperly clamped bur may dislodge during use, causing injury to you
16:1 Endodontic Motor
or your patient. A sudden high-pitched sound or increased vibration while handpiece is operating alerts the
to Angle Adapter
operator to the possibility that the chuck is not latched properly to retain the bur or a bent bur is inserted.
64:1
CAUTION
300
TO MINIMIZE RISK OF INJURY OR DAMAGE TO ANGLE:
TITAN BALL BEARING
• Replace cartridge when handpiece does not run at full speed or runs noisily.
AUTO LATCH ANGLE HEAD
• Follow these safety instructions:
- Confirm bur is secure by tugging on it after it is loaded
KNURLED RING
- Verify concentric rotation by operating handpiece outside oral cavity. Do not use if it does not
SPLINES
run concentrically or runs with excessive noise.
KNUCKLE
- Do not operate angle without an installed bur.
FIG.1
- Always use burs with overall length of less than 24mm. Shank length must be at least 7.3mm.
- When using auto chuck angle, never depress end cap while bur is rotating.
BALL BEARING
MANUAL LATCH
MATING
ANGLE
INDENTATIONS
DISCONNECT
WRENCH
MOTOR-TO-ANGLE
ADAPTER DRIVE GEAR
MOTOR-TO-
ANGLE ADAPTER
FIG.2
FIG.3
TITAN BALL BEARING
AUTO LATCH ANGLE
PUSH ON
CENTER OF END CAP
UNLOCKED
POSITION
FIG.5
LUBRICATION - For Lubricated Angles ONLY
Lubricate the Transmission Gear Daily
1. To disassemble angle: unthread knurled ring. Remove
knuckle and transmission gear from angle head.
2. Place a drop of DentaLube II in the two transmission gear
(FIG. 6) joints between the gear and gear housing and a
drop of DentaLube II in the hole in the center of the gear
housing. Rotate the gears to allow DentaLube II to work
into the bearings. Apply a light coat of DentaLube II to the
gear teeth.
3. To reassemble angle, insert transmission gear into angle
head. Engage splines of knuckle with mating splines of
head to achieve proper alignment.
4. Tighten knurled ring onto knuckle threads until snug.
5. Place angle on motor, connect to handpiece tubing; insert bur and run for 20 seconds to evenly distribute
lubricant and disperse any residual lubricant.
6. Proceed to Cleaning & Sterilization procedures before use.
LubeFree Angles denoted by having 3 rings on neck - see image on first panel - are lubricated
NOTICE
for life. Never clean ultrasonically or immerse in solvent that would dilute the lubricant.
CARTRIDGE REPLACEMENT
REPLACEMENT OF THE AUTO LATCH CARTRIDGE
1. Unthread knurled ring.
2. Remove knuckle and transmission gear from head.
3. Unthread end cap using end cap wrench, StarDental Part #261339 (FIG. 7). Note
the order and orientation of components when removed from head. Reverse the
order when reassembling cartridge.
NOTE: Remove transmission gear first before removing cartridge from head (FIG.8.)
CARTRIDGE ALIGNMENT TAB
MATING
GEAR AND
GROOVE
SMALL BEARING
WAVE
END CAP
WASHER
4. Pushing from the front of the head, remove the cartridge by using a 3/32" pin (FIG. 10).
5. Clear housing of all dirt, debris, and/or remaining parts of previous cartridge. Install new wave
washer - supplied with new cartridge. Insert new cartridge by installing gear and small bearing end
first. Slide cartridge into housing with alignment tab of cartridge mating with groove in head. Install
end cap.
6. To reassemble angle, insert transmission gear into angle head. Engage splines of knuckle with
mating splines of head to properly align.
7. Tighten knurled ring onto knuckle threads until snug.
REPLACEMENT OF THE MANUAL LATCH CARTRIDGE
1. Unthread knurled ring.
2. Remove knuckle and transmission gear from head.
NOTE: Remove transmission gear first before removing
cartridge from head.
3. Unthread end cap using plastic wrench (FIG. 9).
4. Position latch arm in the unlocked position.
5. At rear of head, push out old cartridge using a 3/32" pin
(FIG. 10).
6. Clear housing of all dirt, debris, and/or remaining parts
of previous cartridge. Insert new cartridge with alignment tab of cartridge
and gears toward end cap and align with mating groove in head. Install
end cap (FIG. 11).
7. To reassemble angle, insert transmission gear into angle head. Engage
splines of knuckle with mating splines of head to achieve proper alignment.
8. Tighten knurled ring onto knuckle threads until snug.
RED TIP APPLICATOR
KNUCKLE TRANSMISSION
KNURLED
GEAR RING
FIG.6
End Cap
Wrench
FIG.7
FIG.8
FIG.9
PLASTIC WRENCH
FIG.10
HEAD
END
CAP
GEARS
3/32"
PIN
MATING
GROOVE
FIG.11
ALIGNMENT
TAB
