Dimensions And Clearances - Zephyr Elica Om Use, Care And Installation Manual

Table of Contents

Advertisement

(vertical-horizontal discharge)
(Vertical discharge only - Duct
bends are not considered)
* Quote for conduit area passage
** Low duct cover kit
***High duct cover kit
Note: Duct cover kits are not supplied. Conduit and ducting area passage for vertical discharge may be different if range
hood is installed withoud these kits.
22" 1/16
31" 1/2
7" 1/16
2" 3/8
Conduit
and Ducting area
passage
32"
28" 5/8*
Side
Cabinet
min. cabinets opening widths
20"
bottom of canopy
to cooking surface
17" 1/2
min 47" 14/16***
max 65" 3/16***
min 38" 13/16**
max 47" 8/16**
29" 7/16
13" 3/4
ceiling
rear
1" 1/4
wall
13" 3/4
Ducting area
passage horizontal
discharge
3" 3/4
10" 7/16
Side
Cabinet
32"
CenterLine
7
www.zephyronline.com
33" 15/16
