e. Remove the blower from the metal filter
housing.
f. Reposition the blower/bracket assembly so that
discharge outlet is towards the top side (Vertical
discharge), firmly tighten the 4 fixing screws.
WARNING! When performing this step check
that wirings run in a proper way, DO NOT
DAMAGE OR PULL WIRINGS!
Vertical
discharge
g. Connect the motor with its molex plug to the
electronic box and fit the wiring inside the wiring
blocks.
Horizontal
discharge
