Operation guide
Parts list (continued)
APP 53-86 - serial no.
up to 06
Pos. Qty. Description
0121 1 Center flange APP H
0122 1 O-ring (ø80.0 x 2 mm)
0124 1 Shaft seal
0125 1 Cover for shaft seal
0126 4 Pin (ø10.5 x 20)
0127 4 Screw M6 x 12 A4-80
0128 30 Screw M8 x 20 BUMAX
0131 1 3" Cover for Inlet port
0132 2 O-ring (ø79 x 3.5)
0133 4 Screw M8 x 16 A4-80
0134 1 3" Cover for Outlet port
0135 4 Screw M10 x 16 A4-80
0140 1 Lifting eye M12 (DIN 580E)
0142 1 Washer for shaft seal
0151 1 O-ring (ø35 x 3)
0152 1 Valve cone
0153 1 Compression spring
0154 1 Plug/guide
0155 1 O-ring (ø47.2 x 3.5)
1 Instruction
Not mounted in APP 53
1)
96 | 180R9346 | AQ240486503020en-001702
Installation, Operation and Maintenance APP 53-92 pumps
Material
1.4462
NBR x
NBR x
1.4462
1.4410 x
A4-80 x
x
A4-100
PP
NBR x
A4-80
PP
A4-80
AISI 316
1.4462 x
NBR x
1.4410
1.4462
1.4410
NBR x
x
x
x x x x x x
x
x
x
x
x
x
x x x x x x
