Wiring
14.
Level indicator
Level and temperature indicators
must be fitted. Follow installation
instructions
15.
Rotation direction
2
1
?
Check pump drive motor rotation
direction matches that of the pump
prior to installation
16.
Bleeding the pump will ensure correct
cooling and lubrication
Missing or incorrectly connected level
and temperature indicators cause
damage
Incorrect rotation direction will
damage the pump
Bleeding
Insufficient bleeding may cause dam-
age (not applicable to Power Packs)
Starting procedure
Cleaning procedure
1. Fill cold water into the system via the return filter and
bleed the pump (Power Packs PPH 4 - 6.3 - 10 and 12.5 are
self-bleeding)
2. Start and bleed the system -without pressure by opening
the bypass valve
3. Add the cleaning agent to give 3% agent/water solution
4. Run the system for 60 min. and activate all components as
often as possible to ensure effective flushing with the
cleaning agent
5. Empty the system of the cleaning agent solution
Flushing procedure
6. Fill cold water through the return filter and bleed the
pump (Power Packs PPH 4 - 6.3 - 10 and 12.5 are
self-bleeding)
7. Run the system for 30 min. and activate all components as
often as possible
8. Empty the system of the water
9. Alternatively the system may be flushed by running the
unit without the return hose while continuously filling up
water. The flushing should continue until there is no trace
of cleaning agent in the return water
10. Change the return filter element, fill cold water through
the return filter and bleed the pump during start up
11. The system is now ready for operation
Starting procedure
60 min.
Observing the starting procedure will
ensure problem-free operation
2-3
days
If the system is not cleaned before
starting, the filter will clog
