Getting Started
PRINTER SERIAL #: 00516645051
PRINTED LABELS: 303
PRINTED INCHES: 1533
TOTAL INCHES: 1571
POWER ON HOURS: 32.8
CUTTER TYPE: Guillotine
CUTTER ENABLED?: YES
CUTTER COUNTS: 1789
KIOSK CUT MODE: Disabled
KIOSK DISTANCE: 0
SWITCH BANK 1: 10001010
SWITCH BANK 2: 01010001
SWITCH BANK 3: 00000000
SWITCH BANK 4: 00000000
SWITCH BANK 5: 00000000
SWITCH BANK 6: 00000001
CURRENT COMM PORT: Autoselect USB/RS232
RS232 PARAMETERS: 115200-N-8-1
PRINT HEAD SIZE: 1280
PRINT HEAD DPI: 300
% CONTRAST: 100
D91 GAP VALUE: 30
TOF DISTANCE: 179
STOCK OUT VALUE: 100
PRINTER CODE REV: 1.11.34
BOOTLOADER CODE REV: 1.00.11
CODE ASSY PN. 071010-011134
3.12 TOF Sensor
The TOF Sensor is used to detect when media is present and is used in conjunction with the
Top-Of-Form operation. A TOF is when the printer uses the sensor to detect the edge of
the media and retracts the configured distance. See the D121 and D123 commands for
more details regarding the TOF operation.
A potentiometer adjusts the distance over which the LPD sensor will detect reflections. The
maximum range may be adjusted over a distance of 0.20" to 0.85". Distances are
measured from the surface of the sensor to the reflecting surface. The sensor is set to the
maximum detection at the factory. This pot may be used to decrease sensor range to avoid
false reflections from stationary objects such as a cutter.
3-36
Figure 3-7 Status Label (Examples)
PRINTER SERIAL #: 00516645051
PRINTED LABELS: 303
PRINTED INCHES: 1533
TOTAL INCHES: 1571
POWER ON HOURS: 32.8
CUTTER TYPE: None
KIOSK CUT MODE: Disabled
KIOSK DISTANCE: 0
SWITCH BANK 1: 10001010
SWITCH BANK 2: 01010001
SWITCH BANK 3: 00000000
SWITCH BANK 4: 00000000
SWITCH BANK 5: 00000000
SWITCH BANK 6: 01110010
CURRENT COMM PORT: Autoselect USB/RS232
RS232 PARAMETERS: 115200-N-8-1
PRINT HEAD SIZE: 1280
PRINT HEAD DPI: 300
% CONTRAST: 100
D91 GAP VALUE: 30
TOF DISTANCE: 160
STOCK OUT VALUE: 100
PRINTER CODE REV: 1.11.34
BOOTLOADER CODE REV: 1.00.11
CODE ASSY PN. 071010-011134
