Chapter 5
1 Enable Full Cut.
^A ^D COMMAND
XX 95 Advance/Retract Distance: This command is used in conjunction with the
tag/tear (^D97), peel-n-dispense (^D98), and cutter (^D99) commands. It is
used to adjust the number of steps the printer will advance the media after
printing has stopped and then retract the same distance so that media is not
wasted. While the maximum value is 64,000 steps, it is not recommended that
the printer advance further than one label size. This may create a paper jam
when the label is retracted back into the printer.
XX 96 Load Advance Delay: The ^Axx specifies the amount time, in milliseconds,
that the printer will delay the repositioning or retraction of the media. For
Example, "^A1000^D96 <CR>" would delay for a period of one second.
X 162 Advance/Retract Speed: This command is used to set the advance/retract
speed that is used in conjunction with the different dispense modes. The valid
arguments for the X value are the DPS speed values for the printer. Please
refer to the DPS and ^D49 sections for valid speed values.
5.9.4 Cutter Hold-off
This command is used to avoid cutting "air" or the leading edge of the first label when
printing and cutting without advancing the label stock. This command is used with the Full
or Partial Cut Mode (^D99), but not the Kiosk Cut Mode. This function will skip a pre-set
number of cuts following a Top of Form. Count resets and begins count at TOF or following
the point where the command is given.
Note: Advance distance must be set at "0" for this command to function.
XX 117 Cutter Hold-off: X represents the number of cuts to skip on the first X labels
following a Top of Form.
5.10 Dispensing Commands
Dispensing commands are commands that advance the media for cutting, tear off, or
presenting and then retract the media to a home position so that media is not wasted.
These dispense commands include Peel-n-Dispense, Tag/Tear, Cutter commands, and
optional media handling commands as well. The following commands define these types of
operations. Most of the dispensing commands require that the printer is configured with an
optional Label Present Detector.
5.10.1 Tag/Tear Operation
This command controls a method of dispensing the media so that the perforation between
labels is positioned on the tear bar or peel edge. Once the label is taken, the label media
retracts and allows proper registration of the next label print. Once the label is taken, the
label media retracts and allows proper registration of the next label print.
X 97 Tag/Tear Operation:
0 Disable Tag/Tear operation.
1 Advance after every print.
2 Advance after copies count.
