Microcom 438T Operator's Manual page 104

Printer Commands
represent the physical characteristics of the printer models. This command is
used in conjunction with the Finish Mode feature; see the D27 command bit
position 8 for more information.
Printer Model Number
203dpi 238/338M Series
300dpi 238/338M Series
X 165 Set the Reflective Dot2Gap Value:
This is the distance of the reflective sensor, which detects blackline
registration marks, to the dot row. This distance is set at the factory and is
typically not needed to be changed. The reflective Dot2gap distances
represent the physical characteristics of the printer models.
Printer Model Number
203dpi 238/338M Series
300dpi 238/338M Series
5.4.6 Auto-size Commands
The auto-size command attempts to automatically calculate important format values for the
label header including LSY, GAP, AGD, SPG, ^D90, and the ^D91 values. The printer
feeds a sample of labels through the GAP sensors and takes an average of the values it
receives. The auto-size command uses the appropriate sensors to detect the registration
marks set by the ^D47 command. Before issuing the auto-size command, verify that the
^D47 is set to the proper setting for the media being used.
When using media that contains a blackline for the registration mark, first execute the
^A1^D47<CR> command sequence before issuing the auto-size command or the results
may be invalid.
When using media that contains a blow-hole, set software switch #4 (^D24 command) for
blow-hole detection and then issue the desired auto-size command before issuing the auto-
size command or the results may be invalid.
5-34
203dpi 438
300dpi 438
203dpi 438T Series
300dpi 438T Series
Table 5-3 Transmissive Dot2Gap Values
203dpi 438
300dpi 438
203dpi 438T Series
300dpi 438T Series
Table 5-4 Reflective Dot2Gap Values
Transmissive Dot2Gap
468
730
264
395
187
276
Reflective Dot2Gap
468
730
487
720
187
276
438T Operator's Manual - 880051-0102
Chapter 5
