Microcom 438T Operator's Manual page 220

^A ^D COMMAND
XX 106 Save ASCII Graphics to RAM:
This command is intended for legacy support only. Microcom Corporation
recommends using the ^D107 command instead of the ^D106.
xxyy 107 Save Compressed GRAPHICS to RAM:
The special ^Axxyy^D107 code is put at the beginning of the GRAPHIC
download file by the bit map converter program. The ^Axxyy tells the printer
the overall size of the file according to this format:
xx The number of additional 64KB sectors needed to save the graphic file.
yy The memory slot location of the graphic being saved; CGN # (1-255)
X 108 Serial Port Source (Non-volatile)
0 Autoselect USB or Serial
1 2 Port Autoselect (USB or Xport Ethernet)
2 USB
3 RS232 Serial
5 Ethernet Option Board
6 3 Port Autoselect (USB, Ethernet option board, or Serial)
Diagnostics mode = Autoselect USB or Serial
Order of detection:
0 (^A0^D108) = USB then Serial
1 = USB then Xport Ethernet
6 = USB, Ethernet Option Board, then Serial
X 110 General Purpose Status Byte
XX 111 Kiosk Cutter Mode: This command enables the non-volatile full and/or partial
cut operation. The ^D112 command is also used with the ^D111 command to
adjust the advance distance to the cutter blades and then retract to the home
position (dot row one).
0 Disable Kiosk Cutter Mode.
1 Enable Kiosk Cutter Mode.
2 Enable partial Kiosk Cutter Mode.
4 Enable full Kiosk Cutter Mode with LTS
XX 112 Kiosk Cutter Advance Distance Command: The valid range is from
0 to 1000 with the recommended distance of .53".
XX 113 Verbose Mode:
0 Disable Verbose Mode.
1 Enable Verbose Mode.
114 GS1 Databar Data Entry Command: The GS1 Databar, formerly known as
the RSS-14, barcode is fully supported by the 324M and 424M printers. There
are 6 different types of GS1 Databar that are supported by the printer:
13-14 438T Operator's Manual - 880051-0101
