FD60

Important

Caution

Safety

Declaration

● Be sure the correct input voltage is supplied to the actuator.
● Be sure the load applied is within the rated load shown on the label.
● Please contact your dealer if you can't have the actuator mounted onto the frame.
● Ambient operation temperature: -20°C ~ +65°C
● Duty cycle: 10%, max. 2 min. continuous operation in 20 min.
● The load should be applied along the axis of the actuator.
● Side load is NOT good for actuators.
● This appliance cannot be used by children or persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction.
Version 1.0
www.moteck.com
User Guide
Load direction
Lateral force
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FD60 and is the answer not in the manual?

Questions and answers

Summary of Contents for MOTECK FD60

  • Page 1 FD60 User Guide Important ● Be sure the correct input voltage is supplied to the actuator. ● Be sure the load applied is within the rated load shown on the label. ● Please contact your dealer if you can't have the actuator mounted onto the frame.
  • Page 2 Installation / Dimensions check: ● Check whether the actuator stops properly when it reaches either the fully extended or retracted position. ● Before the actuator is mounted, make sure the extension tube is at its most retracted position. Retracted length Stroke / Mounting check: ●...
  • Page 3 Moteck control boxes. If it's not the case, please make sure motor is short-circuited when it stopped. ● If FD60 is NOT used with Moteck control boxes, make sure the actuator is used within the respective load and current, as described in the datasheet.
  • Page 4 DIN 41529 connector (for TL2 only) ©2018 MOTECK Printed in Taiwan. The contents of this publication are the copyright of the publisher and may not be copied or even extracted unless prior written permission is authorized. ©2018 Sep. MOTECK. MO-FAM-I-0011 Version: 1.0...
