- Page 1 Actuator ID10 2022.04_V2.0 Revision Technical changes may be made to improve the product without notice！...
- Page 2 CAUTION ● Be sure that the load acts on the actuator in the axial direction and it isn't recommended to have side load acts on the actuator. Load The load should be centered on the operating direction. Side load is NOT good for actuators.
- Page 3 MANUAL DRIVE (MD) CONNECTOR The MD (manual drive) is an alternative way to drive the motor directly, if the power is not available. Step 1. Remove the plug on the gearbox cover. Step 2. Use a 8.0mm hex bit or electric screwdriver (recommended) to drive the gear directly.
-
Page 4: Wire Connection
WIRE CONNECTION For ID10 actuator, connection rule of power wires varies according to different types and gear ratio(s). Please follow the instructions below. ● Standard (without Limit switch nor positioning feedback) Gear ratio: 5:1, 10:1, 20:1 Wire color Definition... -
Page 5: Safety Declaration
Terms of Use The user is responsible for the suitability of MOTECK products, and the products listed on the MOTECK website are subject to change without notice. MOTECK reserves the right to terminate sales or delete any products displayed on the website or listed in its catalog.
