DONE
To configure from parallel NOR
CE
Flash, remove Jumper J46 to
PROM
disable the Platform Flash PROM
GND
J46
M0
To configure from parallel NOR
M1
Flash, set the FPGA mode select
pins using Jumper J46 as shown
M2
J26
Spartan-3A/3AN Starter Kit Board
M29DW323DT x8/x16 Parallel NOR Flash
STMicroelectronics
M29DW323DT
32 Mbit, x8/x16
parallel NOR Flash
TM
