Connections

Figure 15 iPAM400 connection points
iPAM400 – REAR
AC INLET
AUX OUT
BATTERY IN STATUS
PORT
100 V LINE OUTPUT ALLOCATION PER STANDARD AMPLIFIER CONFIGURATION:
4 x MX100 CONFIGURATION:
MX100
SLOT 4
2 x MX200 CONFIGURATION:
MX200
iPAM400 – Product Manual
AUDIO I/O EXPANSION MODULE (OPTIONAL)
AUDIO INPUTS
LOW LEVEL AUDIO OUTPUTS
SLOT 4
MX100 MX100 MX100
SLOT 3 SLOT 2 SLOT 1
MX200
SLOT 3 SLOT 1
U-0629-0171.doc – Issue: 04 complete, approved
NOT USED
AUDIO IN/RS485 PORTS
INPUT 2 INPUT 1
STANDBY IN
SLOT 3
SLOT 2
100 V LINE OUTPUTS
1 x 200 W + 2 x 100 W CONFIGURATION:
1 x MX400 CONFIGURATION:
Page 39 of 138
iPAM400 – FRONT
(FRONT PANEL REMOVED)
O
I
The rear RS232
PORT is also
duplicated on the
front of the
iPAM400, behind
the removable
front panel.
RS232
VGA ETHERNET
SLOT 1
MX100 MX100 MX200
SLOT 4 SLOT 3
MX400
1
USB
2
SLOT 1
SLOT 1
