ASL INTERCOM iPAM400 Product Manual page 87

5. Test 1. Play 1k
tone
2. Play pink
noise
3. Play
1k/pink test
4. Play test
message to an
output
5. Play test
message to
zone
6. Play
message from
stick to a
zone
7. Restart software (with no logging)
8. Restart software (with logging)
C. Cancel
6. File 1. Delete logs
Management
2. Copy logs and configs to stick
3. Collate DVA filenames to USB flash
drive
C. Cancel
7. X400 1. Clear configuration
C. Cancel
iPAM400 – Product Manual
Menu
{output list}
C. Cancel
{output list}
C. Cancel
{output list}
C. Cancel
{output list}
C. Cancel
{zone list}
C. Cancel
{DVA {zone
list} list}
C. Cancel
C. Cancel
U-0629-0171.doc – Issue: 04 complete, approved
Page 87 of 138
To
Play a 1 [kHz] test tone for approx. 30
seconds to a local output of the user's
choosing.
Return to previous menu.
Play pink noise ("static") for approx. 30
seconds to a local output of the user's
choosing.
Return to previous menu.
Play a 1 [kHz] test tone followed by the pink
noise to a local output of the user's choosing
in a continuous loop.
User can stop the test by pressing ENTER.
Return to previous menu.
Play the test message
(/dva/msgs/test.wav) to a local output
of the user's choosing.
Return to previous menu.
Play test message to zone of user's
choosing.
Zone can either be a local output or any
configured remote output.
Return to previous menu.
Play a message of the user's choosing from
an attached USB memory stick to zone of
the user's choosing.
Zone can either be a local output or any
configured remote output.
Return to previous menu.
Return to previous menu.
Restart the DVA processes.
Restart the DVA processes with debug
logging enabled, i.e. log files will be created
in the /dev/shm/ directory.
Return to main menu.
Erase all currently existing log files in the
/dev/shm/ directory.
Note that all log files will be deleted in the
event of a reboot.
Copy all log files in the /dev/shm/
directory, and all xml and cfg configuration
files in the in the /dva/config/ directory
to the root of an attached USB memory
stick.
Create a directory named after the host in
the root of the attached USB memory stick
and create a file 'msgs' in that directory
containing a list of all DVAs that reside in
the /dva/msgs directory and sub-
directories.
Return to main menu.
Clear amplifier mainframe configuration.
See Note 4).
Return to main menu.
