Mechanical Dimensions

Figure 25 Mechanical dimensions
M odular Power Am plifier
s upply s elec t
1) ASL recommend a rear clearance depth of at least 110 mm for cabling.
A 19-inch standard rack with 600 mm depth provides the required room for installation
including the rear cabling.
2) In order for customers to produce their own site documentation drawings of the front and
rear panel are available from ASL.
iPAM400 – Product Manual
(C onnectors, blanking and fixing plates, fuse, and screw s not show n on rear panel.)
439 m m
436 m m
-0dB -0dB -0dB
100W 100W 100W
-20dB -20dB -20dB
fault -40dB s upply s elect fault -40dB supply s elec t fault -40dB
F ront panel show n fitted (4 x M X100 configuration show n as exam ple.)
approx 487 m m (including h andles)
U-0629-0171.doc – Issue: 04 complete, approved
m ains
battery
aux
ethernet
proc es s or
-0dB s ync
100W
-20dB fault
s upply s elec t fault -40dB
Page 124 of 138
TH IR D A N G LE P R OJEC TION
