2
Connections
Figure 18
DAX200 – Connectors
SPEAKER OUTPUT DETAIL
FAULT A
FAULT B
A+
A–
SPEAKER
OUTPUT 1
DAX200/DAX400 – Installation Guide
B–
B+
SPEAKER
SPEAKER
OUTPUT 2
OUTPUT 3
TOP VIEW
DAX200
(DAX400 has the same connectors at same locations.)
Issue: 02 complete, approved
Page 14 of 28
SPEAKER
OUTPUT 4
BATTERY
SWITCH
MAINS
SWITCH
MAINS
INPUTS
