EV-ADF4355SD1Z User Guide

EVALUATION AND TEST

To evaluate and test the performance of the ADF4355, use the
following procedure:
1. Install the ADF4355 software (see the
Installation Guide).
2. Follow the hardware driver installation procedure
(Windows XP only).
3. Connect a 50 Ω terminator to RFOUTA−.
4. Connect the EV-ADF4355SD1Z
5. Connect the 6 V power supply to the banana connectors
and power-on the board using S1 (check that LED1 is on).
6. Connect the USB cable from the
7. Run the ADF4355 software.
8. Select ADF4355 and SDP board (black) in the Select
Device and Connection tab of the software front panel
display window (see Figure 2).
9. Click the Main Controls tab, and set the VCOout (MHz)
to a frequency of 5000 MHz.
10. Click Write All Registers.
11. Connect the spectrum analyzer to SMA connector
RFOUTA+, see Figure 4 for a typical evaluation setup.
12. Measure the output spectrum and single sideband phase
noise.
PLL Software
board to the SDP-S board.
SDP-S board to the PC.
Figure 6 shows a phase noise plot of the SMA RFOUTA+ equal
to 5 GHz.
–70
–80
–90
–100
–110
–120
–130
–140
–150
–160
–170
1k 10k 100k
FREQUENCY OFFSET (Hz)
Figure 6. Single Sideband Phase Noise
UG-805
–70
–80
–90
–100
–110
–120
–130
–140
–150
–160
–170
1M 10M
