• Select default Ring Pattern (shown as distinct ring pattern 2)
• Click OK when finished.

Establishing a Direct Connection

Note:

For Direct Cable Connection Operation

1. From the TAS-2000 Control Panel window select "Configure Serial".
2. Select "Direct Cable Connection" and verify that the COM port is set
properly.
3. Click OK to continue.
Note:
4. Verify the Lobby Panel ID by checking the SW2 DIP switch settings on
the main board in the lobby panel. Refer to the TAS-2000 Series
Installation and Operation Manual for the DIP switch settings.
5. Note the panel ID and select the same lobby-ID in the TAS-2000
software.
For Modem connections, skip to Establishing a Modem
Connection on page 9.
The panel ID in the TAS2000 software must be set correctly in
order to Upload or Download data.
TAS-2000 MSW-003 Software Manual
7
