Specifications And Features - Lectrosonics DCR822 Instruction Manual

DCR822

Specifications and Features

Receiver
Operating Frequencies (MHz):
Model A1/B1: 470.100 - 614.375
Model B1/C1:
941:
961:
NOTE: It's the user's responsibility to select the approved frequencies for
the region where the transmitter
is operating.
Frequency Selection Steps: 25 kHz
Frequency Response:
Frequency Stability:
Front end bandwidth:
Sensitivity:
weighted
weighted
AM rejection:
Modulation acceptance:
Spurious rejection:
Third order intercept:
Diversity method:
Antenna inputs:
Audio output:
Ohm,
Audio Performance (overall system):
THD:
SNR at receiver output (dB):
Note: The dual envelope "soft" limiter
provides exceptionally good handling
of transients using variable attack and
release time constants. Once activated,
the limiter compresses 30+ dB of transmitter input range into 4.5 dB of receiver
output range, thus reducing the measured figure for SNR without limiting by 4.5 dB
Input Dynamic Range:
Overall Latency (time delay):
Audio Test Tone:
Controls:
Front Panel:
Buttons
Rear Panel:
External Power:
Battery Life:
Lithium
Weight:
Dimensions:
28
537.600 - 691.175
941.525 - 959.825
961.100 - 1014.900
25 Hz to 20 kHz (+0/-3 dB)
±0.001 %
±5.5 MHz, @ -3 dB
20 dB Sinad: 0.9 uV(-108 dBm), A
60 dB Quieting: 1.12 uV (-105 dBm), A
>60 dB, 2 uV to 1 Volt
85 kHz
85 dB
+15 dBm
Vector Diversity (advanced true diversity)
Dual SMA female jacks; 50 Ohm impedance
Rear panel 2 TA3M connectors; can drive 600
adjustable from -50 to +7 dBu in 1 dB steps
(into nominal 10 k bal. load)
0.2% (typical)
SmartNR No Limiting
OFF 103.5
NORMAL 107.0
125 dB (with full Tx limiting)
1.4 ms with digital source, <2.9 sm with Hybrid TX
1 KHz, -50 to +7 dBu, <1%THD
• LCD display
• Menu/Sel, Pwr/Back, Up/Down Arrow
• SD Card Reader
• IR Port
• Analog/AES audio output jack (2)
• External DC input
• Battery compartment
• USB port
Minimum 9 Volts to maximum 17 VDC
2.5 W; 170 mA at 12 VDC
6 hrs. continuous, w/ 4 disposable, 1.5VDC
AA batteries (recommended)
408 grams with batteries (14.4 oz.)
3.23" wide x 1.23" high x 5.50" deep
82 wide x 31 high x 140 deep mm
Recorder
Storage media:
File format:
A/D converter:
Sampling rate:
Recording modes/Bit rate:
Audio Performance:
Frequency response:
Dynamic range:
Distortion:
Operating temperature range:
Celsius:
Fahrenheit:
Specifications subject to change without notice.
Available Recording Time
Using a microSDHC memory card, the approximate recording times are as follows. The
actual time may vary slightly from the values listed in the tables.
Card 1 Track
Size Hrs:Min
8 GB 15.30
16 GB 31.00
32 GB 62.00
w/Limiting
FCC Notice
108.0
NOTE: This equipment has been tested and found to comply with the limits for a
111.5
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by Lectrosonics,
Inc. could void the user's authority to operate it.
microSDHC memory card
.wav files (BWF)
24-bit
48 kHz
24 bit - 144 kbytes/s per channel (up to 4)
25Hz to 20 kHz; +0/-3 dB
110 dB (A), before limiting
< 0.035%
-20 to 50
-5 to 122
2 Tracks 3 Tracks
Hrs:Min Hrs:Min
7.45 5.10
15.30 10.20
31.00 20.40
LECTROSONICS, INC.
4 Tracks
Hrs:Min
3.53
7.45
15.30
