Firmware Update

Firmware updates are made using a microSDHC memory
card. Download and copy the following firmware update
files to a drive on your computer.
• DCR822 vX_XX.hex is the microprocessor firm-
ware update file, where "X_XX" is the revision
number.
• DCR822_fpga_vX_XX.mcs is the FPGA firmware
update file, where "X_XX" is the revision number.
Please check your existing version numbers and then
update either or both files if there are newer ver-
sions available.
In the computer:
1) Perform a Quick Format of the card. On a
Windows-based system, this will automatically
format the card to the FAT32 format, which is the
Windows standard. On a Mac, you may be given
several options. If the card is already formatted in
Windows (FAT32) - it will be greyed out - then you
do not need to do anything. If the card is in another
format, choose Windows (FAT32) and then click
"Erase". When the quick format on the computer is
complete, close the dialogue box and open the file
browser.
2) Copy the DCR822 vX_xx.hex and DCR822_fpga_
vx_xx.mcs files to the memory card, then safely
eject the card from the computer.
In the DCR822:
1) Leave the DCR822 turned off and insert the mi-
croSDHC memory card into the slot.
2) Hold down both the UP and DOWN arrow buttons
on the receiver and turn the power on.
3) The device will boot up into the firmware update
mode with the following options on the LCD:
• Update - Displays a scrollable list of the program
files on the card.
• Power Off - Exits the update mode and turns the
power off without updating.
NOTE: If the unit screen shows FORMAT
CARD?, power the unit off and repeat step 2.
You were not properly pressing UP, DOWN and
Power at the same time.
4) Use the arrow buttons to select Update, then
press the MENU/SEL button. Use the UP and
DOWN arrow buttons to select the desired file and
press MENU/SEL to install the firmware. The LCD
will display status messages while the firmware is
being updated.
5) When the update is complete, the LCD will display
this message: UPDATE SUCCESSFUL REMOVE
CARD. Remove the memory card or use the back
button to return to the update page.
Rio Rancho, NM
Dual Channel Digital Receiver
6) Once finished with updates, power the unit back
on. Verify that the firmware version was updated by
opening the Power Button Menu and navigating to
the About item.
7) If you re-insert the update card and turn the power
back on for normal use, the LCD will display a
message prompting you to format the card:
If you wish to record audio on the card, you must
re-format it. Select Yes and press MENU/SEL to
format the card. When the process is complete, the
LCD will return to the Main Window and be ready
for normal operation.
If you choose to keep the card as is, you may re-
move the card at this time.
The firmware update process is managed by a bootload-
er program - on very rare occasions, you might need to
update the bootloader.
WARNING: Updating the bootloader can
corrupt your unit if interrupted. Don't update
the bootloader unless advised to do so by the
factory.
• DCR822_boot vX_XX.hex is the bootloader file
Follow the same process as with a firmware update and
select the DCR822boot file.
NOTE: The ability to perform firmware updates
via the USB port will be built into a future
update. Check the Firmware Release Notes as
updates are announced.

DCR822 and Wireless Designer

The DCR822 is now supported in the current version of
Wireless Designer via USB connection. Be aware of the
following when preparing to connect your DCR822 to
Wireless Designer via USB:
The DCR822 must have the micro and FPGA firmware both
updated to v1.30 or higher. Wireless Designer version must
be at least 2.0.30 for macOS, or version 2.0.34 or higher for
Windows. These are available on our Support website at:
https://www.lectrosonics.com/wireless-designer.html.
Format Card?
(files lost)
• No
• Yes
