DCR822

Specifications and Features

Receiver
Operating Frequencies (MHz):
Model A1/B1:
Model B1/C1:
941:
Frequency Selection Steps:
Frequency Response:
Frequency Stability:
Front end bandwidth:
Sensitivity:
AM rejection:
Modulation acceptance:
Spurious rejection:
Third order intercept:
Diversity method:
Antenna inputs:
Audio output:
Audio Performance (overall system):
THD:
SNR at receiver output (dB):
Note: The dual envelope "soft" limiter
provides exceptionally good handling
of transients using variable attack and
release time constants. Once activated,
the limiter compresses 30+ dB of transmitter input range into 4.5 dB of receiver output range, thus
reducing the measured figure for SNR without limiting by 4.5 dB
Input Dynamic Range:
Overall Latency (time delay):
Audio Test Tone:
Controls:
Front Panel:
Rear Panel:
External Power:
Battery Life:
Weight:
Dimensions:
Recorder
Storage media:
File format:
A/D converter:
Sampling rate:
Recording modes/Bit rate:
28
NOTE: It's the user's
responsibility to select the
approved frequencies for the
470.100 - 614.375
region where the transmitter
537.600 - 691.175
is operating.
941.525 - 959.825
25 kHz
25 Hz to 20 kHz (+0/-3 dB)
±0.001 %
±5.5 MHz, @ -3 dB
20 dB Sinad: 0.9 uV(-108 dBm), A weighted
60 dB Quieting: 1.12 uV (-105 dBm), A weighted
>60 dB, 2 uV to 1 Volt
85 kHz
85 dB
+15 dBm
Vector Diversity (advanced true diversity)
Dual SMA female jacks; 50 Ohm impedance
Rear panel 2 TA3M connectors; can drive 600 Ohm,
adjustable from -50 to +7 dBu in 1 dB steps
(into nominal 10 k bal. load)
0.2% (typical)
SmartNR No Limiting
OFF 103.5
NORMAL 107.0
FULL 108.5
125 dB (with full Tx limiting)
1.4 ms with digital source, <2.9 sm with Hybrid TX
1 KHz, -50 to +7 dBu, <1%THD
• LCD display
• Menu/Sel, Pwr/Back, Up/Down Arrow Buttons
• SD Card Reader
• IR Port
• Analog/AES audio output jack (2)
• External DC input
• Battery compartment
• USB port
Minimum 9 Volts to maximum 17 VDC
2.5 W; 170 mA at 12 VDC
6 hrs. continuous, w/ 4 disposable, 1.5VDC Lithium
AA batteries (recommended)
408 grams with batteries (14.4 oz.)
3.23" wide x 1.23" high x 5.50" deep
82 wide x 31 high x 140 deep mm
microSDHC memory card
.wav files (BWF)
24-bit
48 kHz
24 bit - 144 kbytes/s per channel (up to 4)
Audio Performance:
Frequency response:
Dynamic range:
Distortion:
Operating temperature range:
Celsius:
Fahrenheit:
Specifications subject to change without notice.
Available Recording Time
Using a microSDHC memory card, the approximate recording times are as follows. The actual
time may vary slightly from the values listed in the tables.
Card
Size
8 GB
16 GB
32 GB
w/Limiting
*microSDHC Logo is a trademark of SD-3C, LLC
108.0
111.5
113.0
FCC Notice
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by Lectrosonics, Inc. could
void the user's authority to operate it.
25Hz to 20 kHz; +0/-3 dB
110 dB (A), before limiting
< 0.035%
-20 to 50
-5 to 122
1 Track 2 Tracks 3 Tracks
Hrs:Min Hrs:Min Hrs:Min
15.30 7.45
31.00 15.30 10.20
62.00 31.00 20.40
LECTROSONICS, INC.
4 Tracks
Hrs:Min
5.10 3.53
7.45
15.30
