Connecting to a Network

Using DHCP for IP Address Assignment

Follow these steps to make a network connection for
the receiver:
1) Open Wireless Designer and connect to the re-
ceiver via USB.
2) Click on Settings in the left pane. Then click on the
Network tab in the lower part of the screen. Inside
the dialog box labeled Network Settings, click on
the check box labeled DHCP Enable.
3) Close Wireless Designer.
4) Connect the network cable to the Ethernet port on
the rear panel.
5) Turn the receiver power off then back on.
6) Launch Wireless Designer again and navigate to
Network Settings as described above. The IP
address and port number will appear in the dialog
box.
7) Close the USB connection and re-connect via
network. When the dialog box opens, enter the IP
address and the port number noted, then click on
Refresh. Click on OK to connect.
Rio Rancho, NM, USA
Digital Hybrid Wireless
Firmware Update
Instructions
Firmware updates are made with a file downloaded
from the web site and a USB connection to the re-
ceiver.
Refer to the Help file in Wireless Designer software for
the procedure.
Modular Receiver System
®
21
