POWER PRO User's Manual

Input

Connector:
Voltage:
Total power:
Protection:

Primary Output

Connector:
Voltage with external power:
Voltage from battery:
Maximum current:
Maximum with external power:
Maximum with battery power:

Secondary Outputs

Connector:
Voltage with external power:
Voltage from battery:
Max. current from external power:
Max. current from battery:
Maximum power:
• •
Introduction Specifications
support.dtsweb.com
4-pin Amphenol MS3474L14-4P
18–36 VDC
450 W
Overvoltage, undervoltage, overcurrent, and reverse polarity protection
•
Using the POWER PRO DataPRO Software Interface
4-pin Amphenol MS3474L14-4S
15 VDC regulated
10.8 VDC nominal; 9–12.6 VDC
14 A with total overcurrent protection including 6 x
LEMO connectors and 12 V–1 A (WET) connector
16 A with total overcurrent protection including 6 x LEMO
connectors and 12 V–1 A (WET) connector
210 W
150 W
Six, 4-pin LEMO ECG.2B.304.CLL
15 VDC regulated
Optional - 10.8 VDC nominal; 9–12.6 VDC
14 A combined with total overcurrent protection including
Primary Output and 12 V–1 A (WET) connector
16 A combined six outputs, regulated output (WET), and
Amphenol
210 W total
•
