Status (STS) Indicator

• The indicator blinks rapidly (green) when the POWER PRO is connected to a DTS software application (DataPRO).
• The indicator is on (solid green) when a high status input is received on either COM port.
• The indicator is on (solid red) when an incoming status high is received AND the POWER PRO reports a fault.
•
The indicator is OFF when no incoming status is present and the POWER PRO is not connected to a DTS software
application (DataPRO).
STS Indicator
Blinking green
Blinking green
Solid red
Solid green
• •
Introduction Specifications
support.dtsweb.com
STS Input
INACTIVE
INACTIVE
ACTIVE
ACTIVE
•
Using the POWER PRO DataPRO Software Interface
Battery/Power
Fault
Good
Fault
Good
•
Care & Handling
15
August 2022
STS Out
INACTIVE
INACTIVE
INACTIVE
ACTIVE
• •
