POWER PRO User's Manual
Connectors – Power Output and Communication
POWER PRO OFF
External Power Applied
External Power Removed

Default Configuration

POWER PRO ON
External Power Applied
External Power Removed

Alternate Configuration

POWER PRO ON
External Power Applied
External Power Removed
• •
Introduction Specifications
support.dtsweb.com
Amphenol (9–15 V Out)
15 VDC
OFF
Amphenol (9–15 V Out)
15 VDC
9–12.6 VDC (Battery)
Amphenol (9–15 V Out)
15 VDC
9–12.6 VDC (Battery)
•
Using the POWER PRO DataPRO Software Interface
Auxiliary LEMO (12 V–1 A)
12 VDC
OFF
Auxiliary LEMO (12 V–1 A)
12 VDC
12 VDC
Auxiliary LEMO (12 V–1 A)
12 VDC
12 VDC
•
Care & Handling
17
August 2022
Power LEMO (9–15 V Out)
Six LEMO connectors in
parallel
15 VDC
OFF
Power LEMO (9–15 V Out)
15 VDC
OFF
Power LEMO (9–15 V Out)
15 VDC
9–12.6 VDC (battery)
• •
