Lemo Output Led Indicator (Alternate Configuration, Lemo On While Running On Battery); 12 V-1 A Lemo Output Led Indicator - DTS POWER PRO User Manual

POWER PRO User's Manual

LEMO Output LED Indicator (Alternate Configuration, LEMO On While Running on Battery)

Output is OFF.
OFF
The POWER PRO is OFF, no input voltage applied
Output is ON (Regulated 15 VDC).
Green
The POWER PRO is OFF, 18–36 VDC input is applied.
Output is ON (Regulated 15 VDC).
Blue
The POWER PRO is ON, 18–36 VDC input is applied.
Output is ON (9–12.6 VDC).
Yellow
The POWER PRO is ON, running on battery
Output is OFF, a power fault has been detected.
Red
12 V–1 A LEMO Output LED Indicator
Output is OFF.
OFF
The POWER PRO is OFF, no input voltage applied
Output is ON (Regulated 12 VDC).
Green
The POWER PRO is OFF, 18–36 VDC input is applied.
Output is ON (Regulated 12 VDC).
Blue
The POWER PRO is ON, 18–36 VDC input is applied.
Output is ON (Regulated 12 VDC).
Yellow
The POWER PRO is ON, running on battery
Output is OFF, a power fault has been detected.
Red
• •
