  • Page 1 DRIVENET 28 EZ USER’S MANUAL rel. 1.0 GB...
  • Page 2 Le informazioni contenute in questo documento sono state attentamente redatte e controllate. Tuttavia non è assunta alcuna responsabilità per eventuali inesattezze. Tutti i diritti sono riservati e questo documento non può essere copiato, fotocopiato, riprodotto per intero o in parte senza previo consenso scritto della D.T.S . D.T.S.

  • Page 3: Table Of Contents

    INDEX: 1- SYMBOLS ......................... 4 2- GENERAL WARNING ....................4 3- GENERAL WARRANTY CONDITIONS ..............4 4- TECHNICAL FEATURES ..................5 5- ACCESSORIES ......................6 6- IMPORTANT SAFETY INFORMATION ..............7 6.1 Fire prevention...................... 7 6.2 Prevention of electric shock .................. 7 6.3 Safety ........................

  • Page 4: 1- Symbols

    1- SYMBOLS Graphic symbols used on this manual: THIS SYMBOL INDICATES ELECTRIC SHOCK RISK THIS SYMBOL INDICATES GENERAL RISK THIS SYMBOL MEANS “SUITABLE FOR INDOOR USE ONLY” THIS SYMBOL INDICATES THE MAXIMUM OPERATING AMBIENT TEMPERATURE THIS SYMBOL INDICATES THE EUROPEAN COMMUNITY DIRECTIVE 2012/19/EU ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)

  • Page 5: 4- Technical Features

    DALI connections 2-pole In/Out screw terminals panel connector Control DMX 512/RDM and DALI protocol 4-digit 7-segment LED display + 4 soft keys Internal operating system updatable via DTS Dongle Firmware Uploader Safety devices Overvoltage circuit protection Protection rating IP20 Operating temperature -10°...

  • Page 6: 5- Accessories

    02M029206.49) 1 x User’s Manual Optional (on request) ● “C” Clamp G50 (Max. Load 10 Kg) (Code 0521A012) ● Safety cable 3 mm x 60 cm, max capacity load 60 Kg (Code 0521A010) ● DTS Dongle Firmware Uploader (Code 03.LA.206)

  • Page 7: 6- Important Safety Information

    6- IMPORTANT SAFETY INFORMATION 6.1 Fire prevention: Replace any blown or damaged fuses only with those of identical value: T 5A 250V. 6.2 Prevention from electric shock: High voltage is present inside the unit. Disconnect power before servicing. This equipment must be grounded, do not connect to non-grounded supplies. The use of a thermal magnetic circuit breaker is recommended for each DRIVENET 28 EZ unit.

  • Page 8: 7- Installation

    7- INSTALLATION The unit is suitable for dry locations only. DRIVENET 28 EZ can be installed on a wall or on a truss thanks to the 2 mounting brackets included (single bracket code 02M029206.49). For wall mounting installation brackets can be mounted on short sides or long sides of the unit.
  • Page 9 Wall mounting with 2 brackets on long sides:...
  • Page 10 For truss mounting installation, it is recommended the use of appropriate clamps to fix the unit to the mounting surface. Suitable fixing clamps are available on demand. ATTENTION: A safety cable must be securely fixed to the unit and to the suspension truss in order to avoid the fixture accidentally falling should the main fixing point fail.

  • Page 11: 8- Input / Output Connections

    8- INPUT / OUTPUT CONNECTIONS...

  • Page 12: 9- Dmx Signal Connection

    9- DMX SIGNAL CONNECTION: The unit operates using a digital DMX 512 signal. Connection between the controller and the unit or between units must be carried out using a two pair screened ø 0.5 mm. Ensure that the conductors do not touch each other. Do not connect the cable ground to the DMX connector chassis.

  • Page 13: Dmx Addresses

    9.1 DMX addresses DRIVENET 28 EZ can be used in 9 DMX channels mode: 10 ch, 8 ch, 4 ch, 2 ch, 1 ch, 8 ch + dimmer, 4 ch + dimmer, 2 ch + dimmer or Custom 8 ch.

  • Page 14: 10- Rdm Functions

    10- RDM FUNCTIONS By using a RDM controller it is possible to set DMX address, DMX mode and other parameters. DRIVENET 28 EZ accepts the following RDM commands: Root Device DEVICE_INFO To read the following parameters: • RDM protocol version •...

  • Page 15: 11- Dali Signal Connection

    By using a DALI controller it is possible to set independently the value of the 8 output channels only if DMX signal is disabled (DMX signal has priority on DALI signal). Searching, addressing and report commands are accepted also if DMX signal is enabled. DRIVENET 28 EZ accepts the following DALI commands: Command Number Description...
  • Page 16 Physical Min Level 1 [0.1%] DALI controllers identify each DRIVENET 28 EZ as 8 DALI gears and automatically assign 8 DALI addresses of the 64 available for each controller. The first gear is assigned at the first DALI address available while the other addresses are assigned consecutively.

  • Page 17: 13- Firmware Updating

    Using these options, it is possible to change the fixture’s setting. Changing the DTS settings can vary the functions of the unit so that it does not respond to the DMX 512 used to control it. Carefully follow the instructions below before carrying out any variations or selections.
  • Page 18 FIRMWARE RELEASE 1.00 RDM Device Model ID 0x0D6E 0x01 “DMX_MODE_10CH” DMX Personality IDs 0x02 “DMX_MODE_8CH” 0x03 “DMX_MODE_4CH” 0x04 “DMX_MODE_2CH” 0x05 “DMX_MODE_1CH” 0x06 “DMX_MODE_D8CH” 0x07 “DMX_MODE_D4CH” 0x08 “DMX_MODE_D2CH” 0x09 “CUSTOM 8 CHANS” MAIN MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION ...

  • Page 19: 15- Dmx Protocol

    MAIN MENU LEVEL 1 LEVEL 2 LEVEL 3 FUNCTION     To restore default settings     LED driver temperature monitoring     Shows the total unit life time and the 8 channel output life time ...
  • Page 20 8 CHANNELS MODE (Default) OUTPUT CHANNEL 1 OUTPUT CHANNEL 2 OUTPUT CHANNEL 3 OUTPUT CHANNEL 4 OUTPUT CHANNEL 5 OUTPUT CHANNEL 6 OUTPUT CHANNEL 7 OUTPUT CHANNEL 8 Name DMX levels OUTPUT CHANNEL 1 0..255 Proportional dimmer from min to max OUTPUT CHANNEL 2 0..255 Proportional dimmer from min to max...
  • Page 21 1 CHANNEL MODE OUT CH 1 + OUT CH 2 + OUT CH 3 + OUT CH 4 + OUT CH 5 + OUT CH 6 + OUT CH 7 + OUT CH 8 Name DMX levels OUTPUT CHANNEL 1 0..255 Proportional dimmer from min to max OUTPUT CHANNEL 2...
  • Page 22 “D4CH” MODE (5 DMX CHANNELS) DIMMER OUTPUT CHANNEL 1 + OUTPUT CHANNEL 2 OUTPUT CHANNEL 3 + OUTPUT CHANNEL 4 OUTPUT CHANNEL 5 + OUTPUT CHANNEL 6 OUTPUT CHANNEL 7 + OUTPUT CHANNEL 8 Name DMX levels DIMMER 0..255 Proportional master dimmer from min to max OUTPUT CHANNEL 1 0..255 Proportional dimmer from min to max...
  • Page 23 11- WIRING DIAGRAMS The maximum number of ARTEMIO FRESNEL connectable to each output channel of the DRIVENET 28 EZ is 1 piece. The maximum distance between DRIVENET 28 EZ and ARTEMIO FRESNEL unit should not exceed 100 meters.
  • Page 24 The maximum number of MINI BRICK ARC connectable to each output of the DRIVENET 28 EZ @ 180-240Vac is 1 piece. The maximum distance between DRIVENET 28 EZ and MINI BRICK ARC unit should not exceed 100 meters. Max Power 280W.
  • Page 25 The maximum number of VICE R FC connectable to each output of the DRIVENET 28 EZ @ 180-240Vac is 12 pieces. The maximum distance between DRIVENET 28 EZ and VICE R FC unit should not exceed 100 meters. Max Power 280W.
  • Page 26 NOTES...
  • Page 27 NOTES...
  • Page 28 ISO 9001:2015 DTS quality system is certified 9001:2015 standard 0517I346 D.T.S. Illuminazione s.r.l. ● Via Fagnano Selve 12- 47843 Misano Adriatico (RN) Italy ● Tel.: +39 0541 611131 Fax +39 0541 611111 info@dts-lighting.it www.dts-lighting.it...
