Cable Reference

DTS recommends that you use cables we supply to ensure compatibility and performance. Contact your DTS
representative for a list of available cables.
9–15 V OUT
Amphenol Output
9–15 OUT
LEMO Output
12 V, 1 A (WET)
LEMO Output
COM Ports

Mounting Considerations

Securely bolt the unit to the test article or dynamic testing device to provide the best shock protection. Mounting methods
and hardware selection should be calculated to withstand expected shock loading and allow proper grounding.
Check bolt tightness periodically to ensure the unit is securely fastened to the baseplate and the baseplate is securely
fastened to the testing platform. (See
• •
Introduction Specifications
support.dtsweb.com
DTS Cable Part
Number
10600-0005x Cable, power (DPP)
10600-0011x Cable, power, long grounded (PPL)
10600-0012x Cable, power, short grounded (PPS), as option
10200-0002x Cable, TDAS status, COM port to green LED
10700-0008x Cable, SYSTEM port to COM port (DRC)
10700-0014x Cable, COM port daisy chain (RDC)
10700-0015x Cable, PC comm, Ethernet via COM port (REC)
10700-0020x Cable, CONTROL port to COM port (VSI to a COM port) (SIR)
10700-0025x Cable, TDAS G5 VDS event (VVB)
10700-0051x Cable, TDAS event/start record/status, COM port to pigtail term
10700-0062x Cable, COM port event to BNC
10700-0063x Cable, COM port to UMBILICAL port
Mounting Specifications
•
Using the POWER PRO DataPRO Software Interface
Description
for the unit's mechanical specifications.)
•
