DTS 4J Instruction Manual

FAULT FINDING
Fault
Mains light is not coming on
Alarm light not working
Alarm does not reset
Energizer alarm does not reset when
the fence is connected, but does reset
when loops are made between fence in
and out
The energizer does not work when there
is a power failure or with the mains off.
Fuse
Strobe light not working
Siren not working
External alarm output not working
WARRANTY
The DTS range of energizers are free from defects in material and workmanship. This warranty extends
for a period of two (2) years and includes lightning protection. The warranty covers repair or replacement,
provided the unit is returned to our workshop. This warranty shall be considered null and void should
repairs be attempted by anyone not previously authorized by:
DTS SECURITY PRODUCTS
BRUNTON CIRCLE
FOUNDERSVIEW
TEL: 086 1000 387
All DTS units are manufactured in accordance to comply with SABS and all legal requirements.
This document is to be retained by the purchaser and must be produced for warranty to be effective.
Action
Make sure the mains plug is connected and plugged in
and switched on. Make sure mains fuse is OK.
Send the unit in for repairs.
Disconnect the fence from the energizer, insert loop wire
between fence in and fence out. If the alarm resets there is
a fence fault. If the energizer does not reset then send the
unit in for repairs.
Make sure the fence wiring is correct. Make sure the fence
is connected in series to make a fence loop. Make sure the
fence loops are made correctly.
Change fuse on the top of the PC Board.
Replace fuse, make sure the battery is charging. Ensure
the battery is fully charged before the unit is used.
Replace strobe light. Make sure there is 12V output to the
strobe.
Replace siren. Make sure there is 12V output to the siren.
Send the unit in for repairs.
3 SIMON PARK
4
DTS ENERGIZER
INSTRUCTION MANUAL
