DTS Megashock 5
Energizer 5J (Indoor installation)
INSTALLATION MANUAL
Comply to: SANS IEC 60 335-2-76
Base plate-mounting instructions
NRCS Ref. no. 7357 10 14
DTS SECURITY
P.O.BOX 3399
EDENVALE
1610
TELEPHONE 086 1000 387
Spartan
+2711 392 5540 (H/O)
Pretoria
+2712 361 5528
Alberton
+2711 907 8846
Natal
+2731 916 3266
E-EEEE
www.dtssecurity.co.za
1
Advertisement
Table of Contents
Related Manuals for DTS Megashock 5
Summary of Contents for DTS Megashock 5
- Page 1 DTS Megashock 5 Energizer 5J (Indoor installation) INSTALLATION MANUAL Comply to: SANS IEC 60 335-2-76 NRCS Ref. no. 7357 10 14 DTS SECURITY P.O.BOX 3399 Base plate-mounting instructions EDENVALE 1610 TELEPHONE 086 1000 387 Spartan +2711 392 5540 (H/O) Pretoria...
- Page 2 Children should be supervised to ensure that they do not play with the appliance. Disclaimer DTS Security Products CC or any of its subsidiary companies does not guarantee that the operation of the product will be uninterrupted or totally error free. Energizer specifications may be altered without prior notification. The installer is referred to the definitions and general requirements in Appendix A.
- Page 3 If connecting leads and electric fence wires are installed near an overhead power line, their height above the ground shall not exceed 3 meters. Where an electric security fence passes below bare line conductors, the highest metallic element shall be effectively earthed for a distance of not less than 5 meters on either side of the crossing point. This height applies either side of the orthogonal projection of the outermost conductors of the power line on the ground surface, for a distance of: 1) 2 meters for power lines operating at a nominal voltage not exceeding 1000 volt.
- Page 4 Process Control Board (PCB Dipswitch selection Dipswitch 1 - ON, Override tamper alarm switch. Dipswitch 1 - OFF, Normal run mode. Dipswitch 2 - ON, Strobe light will stay on when energizer is armed. Dipswitch 2 - OFF, Strobe light on alarm will stay on until manually reset. Dipswitch 3 - ON, Siren will on alarm go on &...
- Page 5 Fence wire connections (Monitored earth) Fence wire connections (Non Monitored earth) DO NOT connect mains earth as fence earth.
- Page 6 External connections Siren Relay 1 Strobe Relay 2 External ON / OFF via Keypad, Receiver or Switch Gate Contact (N/O) (Components used must be in LATCH mode) Manual or Standard method of arm & disarming the fence & Fence Status 1) Low battery - Service LED will flash equal ON / OFF flashes.
- Page 7 If the 3.15 fuse is blown, the energizer will not work of the battery. (Reversed polarities will blow the fuse). DTS Two Channel onboard receiver Adding a Transmitter Key to CH1 (Arm) (Switching the energizer ON/OFF): 1) Press and release the “Arm” push button to enter the learn mode. The Red RX LED will come on, indicating that the “learn”...
- Page 8 (Excluding the battery which will be 12 months) • All goods are warranted to be free from faulty components and manufacture. • Faulty goods will be repaired or replaced at the sole discretion of DTS Security Products, free of charge.
