Features

• One Amphenol input
o 18–36 VDC with overvoltage, undervoltage, overcurrent, and reverse polarity protection
• One Amphenol output
o Regulated 15 VDC, 14 A max with input power
o 9–12.6 VDC max, 16 A when powered by internal battery
o Maximum delivered 16 A current from the internal battery is distributed between the Amphenol output, six
LEMO outputs, and one LEMO output Wireless Ethernet Terminal (WET)
o Can be configured to be on or off when external power is removed (default is on)
• Six LEMO outputs
o Regulated 15 VDC, 14 A max total with input power
o 9–12.6 VDC, 16 A max total when powered by internal battery
o Maximum delivered 16 A current from the internal battery is distributed between the Amphenol output, six
LEMO outputs, and one LEMO output (WET)
o Not powered by battery by default, but can be configured to be on when external power is removed
• One LEMO output
o Regulated, 12 VDC, 1 A max for use with accessories such as a TDAS PLUS Wireless Ethernet Terminal
(WET)
o Maximum delivered 16 A current from the internal battery is distributed between the Amphenol output, six
LEMO outputs, and one LEMO output (WET)
• Two standard DTS COM ports
• Multicolor LEDs display the state of each output and system status
• Configuration and status can be monitored via software or internal web page
• All critical settings are retained if the unit loses power
• Firmware is upgradable by the end user using a SLICE utility
• •
