POWER PRO User's Manual
If input power is disconnected and the POWER PRO is on, any attached and powered TDAS and SLICE equipment will
use their internal battery reserves first until levels are low enough to begin drawing power from the POWER PRO. When
the available capacity drops below 5%, a fault will occur.

Power Requirements of TDAS and SLICE Equipment

TDAS and SLICE DAS use extensive power management to minimize power consumption. The lowest power demand
condition is during charging when power is off. Current demand is at its maximum when the systems are fully armed and
powering full sensor loads. Power requirements for TDAS PLUS equipment vary greatly; please review the appropriate
user manual for information. TDAS and SLICE User's Manuals are available from the Help menu within your software or
downloadable from the Help Center.
Power Consumption
(per item)
TDAS PRO
- SIM, TOM, DIM
- Rack
TDAS G5 VDS
SLICE PRO
For example, the minimum current required to charge a TDAS PRO rack with 4 modules is 700 mA; the maximum current
required for the same system when operational is 5 A.
• •
Introduction Specifications
support.dtsweb.com
A solid red STS LED indicates a fault signal
from the POWER PRO.
(charging battery)
25 mA
600 mA
600 mA
500 mA
•
Using the POWER PRO DataPRO Software Interface
Warning
Power Off
(armed + max load)
1 A
1 A
2 A
1 A
•
Care & Handling
23
August 2022
Power On
• •
Connectors
10400-00210-MAN (Rev. 0)
