AD8450-EVALZ/ADP1972-EVALZ User Guide
Table 5. Analog Control Board Bill of Materials
Reference Designator
C1, C2, C13, C14, C17, C18, C20, C21, C23,
C24, C38, C39, C84 to C86, C88 to C90
C12, C27, C36, C41, C57, C60, C63, C65, C66,
C72, C73, C76, C78
C3, C15, C19, C22, C25
C37, C42, C45 to C49, C64
C4, C6, C11, C26, C28, C30, C32, C34, C50, C56,
C59, C62, C67, C68, C70, C71, C74, C75, C77, C79
C40
C43, C44
C5
C51, C52 to, C55, C58, C61
C7, C16, C87
C8, C10, C80 to C83
C9
D1
D2
D3 to D5
D6
FB1, R65, R108
FU1, FU2
J2
J3
J4
JP1, JP2
L1
Q1
R1, R2, R6, R8 to R10, R12, R15, R18, R22 to R24,
R29, R33, R36, R41, R42, R47, R49 to R55, R85,
R91 to R93, R97, R102, R107, R120 to R129
R11, R16, R17, R19, R27, R28, R30, R35, R38,
R39, R40, R43 to R45, R58, R61, R64, R74, R90,
R95, R98, R101, R105, R106
R130
R25
R3, R7, R96, R100, R116, R117 to R119
R37, R56, R57, R66, R69, R70, R75 to R77, R87,
R94, R103, R104
R4, R5, R13, R14, R20, R21, R26, R31, R32, R34,
R46, R48, R60, R88
R59
R63, R71, R79
R67
R68
R72, R73, R78, R80 to R84, R86, R89, R99,
R109, R110 to R115
TP1 to TP7
U1
U2
U3
U4
U5
U6
U7
U8
Description
Not applicable
Ceramic capacitor, 0603, 1.0 μF, 25 V
Ceramic capacitor, 0603, 10 nF, 50 V, X7R
Ceramic capacitor, 1206, 50 V, 4.7 μF
Ceramic capacitor, 0603, X7R, 50 V, 100 nF
Ceramic capacitor, 0603, 47 pF, 50 V
Tantalum capacitor, 50 V, 10 μF
Ceramic capacitor, 10 μF, 10 V, X7R, 0805
Ceramic capacitor, 0603, 100 pF, 50 V
Not applicable
Ceramic capacitor, 0603, 1 nF, 50 V
Ceramic capacitor, 0805, 10 nF, 25 V, C0G
Not applicable
Not applicable
Yellow LED
Zener diode, 12 V, 0.2 W
0 Ω (jumper), 125 mW
Fuse, 1206, fast, 125 mA
Connector, DIN41612, B/2, 32
Connector
SDP connector
Jumper, 2211S-03G
Not applicable
Transistor, NPN, SOT89, 0.9 W
Resistor, 0603, 0 Ω (jumper), 1%
Not applicable
Not applicable
Resistor, 0603, 11 kΩ
Resistor, 0603, 1 kΩ, 0.1%, 0.1 W
Resistor, 0603, 4.7 kΩ, 1%
Resistor, 0603, 10 kΩ, 1%
Resistor, 0603, 20 kΩ, 1%
Resistor, 0603, 100 kΩ, 1%
Resistor, 0805, 4.7 kΩ, 1%
Resistor, 0805, 200 Ω, 1%
Resistor, 0603, 1%, 50 ppm, 33 Ω
Test point
Precision analog front end and controller
for testing and monitoring battery cells
Asynchronous buck or boost PWM controller
20 V, high input voltage LDO
Charge pump voltage inverter
Fast settling, highly accurate, low power,
8-/16-channel, multiplexed ADC
EEPROM
5 V, high precision, low power, low noise
voltage reference
Dual, 16-bit, rail-to-rail, voltage output DAC
Rev. 0 | Page 23 of 33
Manufacturer Part Number
Not applicable Not applicable
Murata GRM188R71E105KA12D
AVX 06035C103KAT2A
AVX 12065C475KAT2A
AVX 06035C104K4Z2A
AVX 06035A470JAT2A
Vishay 293D106X9050D2TE3
TDK C2012X7R1A106K125AC
AVX 06035A101JAT2A
Not applicable Not applicable
AVX 06035A102JAT2A
Kemet C0805C103J3GACTU
Not applicable Not applicable
Not applicable Not applicable
Rohm SML-311YTT86K
ON Semiconductor MM3Z12VT1G
Vishay CRCW08050000ZSTA
Littelfuse 0466.125NR
Harting 09 22 232 6825
TE Connectivity 1776275-2
Hirose FX8-120S-SV(21)
Multicomp 2211S-03G
Not applicable Not applicable
Diodes, Inc. 2DD2679-13
Vishay CRCW06030000Z0EA
Not applicable Not applicable
Not applicable Not applicable
Multicomp MC0063W0603111K
Panasonic ERA3AEB102V
Vishay CRCW06034K70FKEA
Vishay CRCW060310K0FKEA
Vishay CRCW060320K0FKEA
Vishay CRCW0603100KFKEA
Vishay CRCW08054K70FKEA
Vishay CRCW0805200RFKEA
Yageo RT0603FRE0733RL
Vero 20-313141
Analog Devices AD8450
Analog Devices ADP1972
Analog Devices ADP7102
Analog Devices ADM8829
Analog Devices AD7173-8
Microchip 24LC32A-I/SN
Analog Devices ADR4550
Analog Devices AD5689R
