HP ProLiant BL45p Generation 2 Server Blade
Maintenance and Service Guide
Part Number 415895-004
September 2007 (Fourth Edition)

Advertisement

Table of Contents
loading

Related Manuals for HP ProLiant BL45p

Summary of Contents for HP ProLiant BL45p

  • Page 1 All manuals and user guides at all-guides.com HP ProLiant BL45p Generation 2 Server Blade Maintenance and Service Guide Part Number 415895-004 September 2007 (Fourth Edition)
  • Page 2 © Copyright 2006, 2007 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Fibre Channel mezzanine......................... 36 NIC mezzanine............................36 I/O signal board ............................ 37 HP Smart Array E200i Controller battery ....................38 HP Smart Array E200i Controller battery cable ................... 39 HP Smart Array E200i Controller cache module ..................39 Heatsink..............................40 Processor ............................... 42 System battery ............................
  • Page 4 All manuals and user guides at all-guides.com Diagnostic tools .......................... 68 Troubleshooting resources ........................68 HP Insight Diagnostics..........................68 HP Insight Diagnostics survey functionality ....................68 Integrated Management Log ........................69 Array Diagnostic Utility ..........................69 HP Systems Insight Manager........................69 HP Instant Support Enterprise Edition......................

  • Page 5: Customer Self Repair

    HP specifies in the materials shipped with a replacement CSR part whether a defective part must be returned to HP. In cases where it is required to return the defective part to HP, you must ship the defective part back to HP within a defined period of time, normally five (5) business days.
  • Page 6 HP sono realizzati con numerosi componenti che possono essere riparati direttamente dal cliente (CSR, Customer Self Repair). Se in fase di diagnostica HP (o un centro di servizi o di assistenza HP) identifica il guasto come riparabile mediante un ricambio CSR, HP lo spedirà direttamente al cliente per la sostituzione.
  • Page 7 La mancata restituzione del componente può comportare la fatturazione del ricambio da parte di HP. Nel caso di riparazione da parte del cliente, HP sostiene tutte le spese di spedizione e resa e sceglie il corriere/vettore da utilizzare.
  • Page 8 Dokumentation in der Verpackung zurückgeschickt werden, die im Lieferumfang enthalten ist. Wenn Sie das defekte Teil nicht zurückschicken, kann HP Ihnen das Ersatzteil in Rechnung stellen. Im Falle von Customer Self Repair kommt HP für alle Kosten für die Lieferung und Rücksendung auf und bestimmt den Kurier-/Frachtdienst.
  • Page 9 Si no enviara el componente defectuoso requerido, HP podrá cobrarle por el de sustitución. En el caso de todas sustituciones que lleve a cabo el cliente, HP se hará cargo de todos los gastos de envío y devolución de componentes y escogerá la empresa de transporte que se utilice para dicho servicio.
  • Page 10 Opcional – Peças cujo reparo feito pelo cliente é opcional. Essas peças também são projetadas para o reparo feito pelo cliente. No entanto, se desejar que a HP as substitua, pode haver ou não a cobrança de taxa adicional, dependendo do tipo de serviço de garantia destinado ao produto.
  • Page 11 All manuals and user guides at all-guides.com Para obter mais informações sobre o programa de reparo feito pelo cliente da HP, entre em contato com o fornecedor de serviços local. Para o programa norte-americano, visite o site da HP (http://www.hp.com/go/selfrepair).
  • Page 12 All manuals and user guides at all-guides.com Customer self repair 12...
  • Page 13 All manuals and user guides at all-guides.com Customer self repair 13...
  • Page 14 All manuals and user guides at all-guides.com Customer self repair 14...
  • Page 15 All manuals and user guides at all-guides.com Customer self repair 15...

  • Page 16: Illustrated Parts Catalog

    Hardware and plastics kit 419530-001 Mandatory a) Heatsink blank — — b) Processor air baffle — — c) Power converter module retainer — — d) Front bezel, HP ProLiant BL45p Generation 2 Server — — Blade, primary Illustrated parts catalog 16...
  • Page 17 All manuals and user guides at all-guides.com Item Description Spare part Customer self number repair (on page 5) e) Front bezel, HP ProLiant BL45p Generation 2 Server — — Blade, secondary* f) Front bezel, HP ProLiant BL25p Generation 2 Server — —...
  • Page 18 Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product.
  • Page 19 Optional: Opcional—Peças cujo reparo feito pelo cliente é opcional. Essas peças também são projetadas para o reparo feito pelo cliente. No entanto, se desejar que a HP as substitua, pode haver ou não a cobrança de taxa adicional, dependendo do tipo de serviço de garantia destinado ao produto.
  • Page 20 All manuals and user guides at all-guides.com Illustrated parts catalog 20...

  • Page 21: Server Blade Components (Secondary Side)

    — b) Processor air baffle — — c) Power converter module retainer — — d) Front bezel, HP ProLiant BL45p Generation 2 Server — — Blade, secondary e) Front bezel, HP ProLiant BL45p Generation 2 Server — — Blade, primary* f) Front bezel, HP ProLiant BL25p Generation 2 Server —...
  • Page 22 Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product.
  • Page 23 Optional: Opcional—Peças cujo reparo feito pelo cliente é opcional. Essas peças também são projetadas para o reparo feito pelo cliente. No entanto, se desejar que a HP as substitua, pode haver ou não a cobrança de taxa adicional, dependendo do tipo de serviço de garantia destinado ao produto.
  • Page 24 All manuals and user guides at all-guides.com Illustrated parts catalog 24...

  • Page 25: Removal And Replacement Procedures

    To reduce the risk of injury from high-current electrical energy, do not remove the server blade access panel when power is applied through the HP ProLiant p-Class diagnostic station. Remove all power from the server blade before removing the access panel.

  • Page 26: Rack Warnings And Cautions

    All manuals and user guides at all-guides.com CAUTION: When performing non-hot-plug operations, you must power down the server blade and/or the system. However, it may be necessary to leave the server blade powered up when performing other operations, such as hot-plug installations or troubleshooting. Rack warnings and cautions WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that:...

  • Page 27: Symbols On Equipment

    All manuals and user guides at all-guides.com CAUTION: Do not operate the server blade for long periods with the access panel open or removed. Operating the server blade in this manner results in improper airflow and improper cooling that can lead to thermal damage. Symbols on equipment The following symbols may be placed on equipment to indicate the presence of potentially hazardous conditions.

  • Page 28: Power Down The Server Blade

    IMPORTANT: Remote power procedures require the most recent firmware for the power enclosure and server blade enclosure management modules. For the most recent firmware, refer to the HP website (http://www.hp.com/go/support). Remove the server blade Identify the proper server blade. Back up all server blade data.

  • Page 29: Access Panel

    All manuals and user guides at all-guides.com CAUTION: To prevent damage to electrical components, properly ground the server blade before beginning any installation procedure. Improper grounding can cause ESD. Access panel Primary access panel WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them.

  • Page 30: Hard Drive

    All manuals and user guides at all-guides.com CAUTION: To prevent improper cooling and thermal damage, do not operate the server blade or the enclosure unless all hard drive and device bays are populated with either a component or a blank. Remove the component as indicated.

  • Page 31: Power Button/Led Board Cable

    All manuals and user guides at all-guides.com To replace the component: Open the release latch and prepare the hard drive for installation. Install the hard drive. Determine the status of the hard drive from the hot-plug hard drive LEDs ("SAS and SATA hard drive combinations"...

  • Page 32: Processor Air Baffle

    All manuals and user guides at all-guides.com Remove the power button/LED board cable. CAUTION: Always align the cable before closing the connector. Failure to align the cable properly can result in damage to the cable or the connector. To replace the component, reverse the removal procedure. Processor air baffle To remove the component: Power down the server blade (on page 28).

  • Page 33: Fan Assembly

    All manuals and user guides at all-guides.com IMPORTANT: To ensure proper cooling, be sure the correct processor air baffle is installed at all times. Fan assembly To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the access panel ("Access panel"...

  • Page 34: Hard Drive Backplane Power And Data Cable

    All manuals and user guides at all-guides.com Hard drive backplane power and data cable To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the access panel ("Access panel" on page 29). Remove the processor air baffle ("Processor air baffle"...

  • Page 35: Dimms

    All manuals and user guides at all-guides.com Remove the hard drive backplane. To replace the component, reverse the removal procedure. DIMMs To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the access panel ("Access panel"...

  • Page 36: Fibre Channel Mezzanine

    All manuals and user guides at all-guides.com Fibre Channel mezzanine To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the access panel ("Access panel" on page 29). Remove the FC mezzanine. To replace the component, reverse the removal procedure.

  • Page 37: I/O Signal Board

    All manuals and user guides at all-guides.com Remove the NIC mezzanine. To replace the component, reverse the removal procedure. I/O signal board To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the secondary access panel ("Secondary access panel"...

  • Page 38: Hp Smart Array E200I Controller Battery

    All manuals and user guides at all-guides.com HP Smart Array E200i Controller battery To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the access panel ("Access panel" on page 29).

  • Page 39: Hp Smart Array E200I Controller Battery Cable

    Remove the server blade (on page 28). Remove the access panel ("Access panel" on page 29). Remove the HP Smart Array E200i Controller battery ("HP Smart Array E200i Controller battery" on page 38). Disconnect the battery cable from the cache module.

  • Page 40: Heatsink

    All manuals and user guides at all-guides.com Disconnect the battery cable from the cache module. Remove the cache module. To replace the component, reverse the removal procedure. Heatsink To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28).
  • Page 41 All manuals and user guides at all-guides.com Remove the heatsink. To replace the heatsink: Use the alcohol swab to remove all the existing thermal grease from the processor. Allow the alcohol to evaporate before continuing. Remove the protective cover from the heatsink. CAUTION: After the cover is removed, do not touch the thermal interface media.

  • Page 42: Processor

    All manuals and user guides at all-guides.com Install the heatsink. Install the access panel. Install the server blade. Processor To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the access panel ("Access panel"...
  • Page 43 All manuals and user guides at all-guides.com Using your fingers, remove the failed processor. To replace the component: CAUTION: The pins on the processor socket are very fragile. Any damage to them may require replacing the system board. CAUTION: Failure to completely open the processor locking lever prevents the processor from seating during installation, leading to hardware damage.
  • Page 44 All manuals and user guides at all-guides.com If the processor has separated from the installation tool, carefully re-insert the processor in the tool. Align the processor installation tool with the socket and install the processor. CAUTION: The processor is designed to fit one way into the socket. Use the alignment guides on the processor and socket to properly align the processor with the socket.
  • Page 45 All manuals and user guides at all-guides.com Press down firmly until the processor installation tool clicks and separates from the processor, and then remove the processor installation tool. Close the processor retaining bracket and the processor retaining latch. Clean the old thermal grease from the heatsink with the alcohol swab. Allow the alcohol to evaporate before continuing.

  • Page 46: System Battery

    All manuals and user guides at all-guides.com Install the heatsink ("Heatsink" on page 40). Install the access panel. Install the server blade. System battery If the server blade no longer automatically displays the correct date and time, you may need to replace the battery that provides power to the real-time clock.

  • Page 47: Power Converter Module

    All manuals and user guides at all-guides.com Remove the battery. IMPORTANT: Replacing the system board battery resets the system ROM to its default configuration. After replacing the battery, reconfigure the system through RBSU. To replace the component, reverse the removal procedure. Power converter module To remove the component: Power down the server blade (on page 28).

  • Page 48: Power Converter Module Retainer

    All manuals and user guides at all-guides.com Remove the power converter module. To replace the component, reverse the removal procedure. Power converter module retainer To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the access panel ("Access panel"...

  • Page 49: Secondary System Board

    All manuals and user guides at all-guides.com Secondary system board To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the secondary access panel ("Secondary access panel" on page 29). Remove the processor air baffle ("Processor air baffle"...
  • Page 50 All manuals and user guides at all-guides.com Using your fingers, remove the failed processor. Disengage the power connector from the chassis. Retain the thumbscrews for future use. Removal and replacement procedures 50...
  • Page 51 All manuals and user guides at all-guides.com Remove the secondary system board. To replace the system board: Install the spare system board in the server blade before installing the processor. Install the power connector onto the chassis. Prepare the processor socket on the spare system board: Removal and replacement procedures 51...
  • Page 52 All manuals and user guides at all-guides.com Remove the processor socket protective cover. Open the processor retaining latch and the processor socket retaining bracket. Install the processor socket cover onto the processor socket of the failed system board. Install the processor on the spare system board. CAUTION: The processor is designed to fit one way into the socket.
  • Page 53 All manuals and user guides at all-guides.com Close the processor retaining latch and the processor socket retaining bracket. Clean the old thermal grease from the heatsink and the top of the processor with the alcohol swab. Allow the alcohol to evaporate before continuing. Apply all the grease to the top of the processor in one of the following patterns to ensure even distribution: CAUTION:...
  • Page 54 All manuals and user guides at all-guides.com Install the heatsink ("Heatsink" on page 40). IMPORTANT: To maintain proper cooling, be sure the processor air baffle is installed at all times. IMPORTANT: Install all components with the same configuration that was used on the failed system board.

  • Page 55: Primary System Board

    All manuals and user guides at all-guides.com Primary system board To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the secondary access panel ("Secondary access panel" on page 29). Remove the processor air baffle ("Processor air baffle"...
  • Page 56 All manuals and user guides at all-guides.com Remove the power converter module ("Power converter module" on page 47). Disconnect all cables connected to the system board ("System board components" on page 75). Remove the heatsink ("Heatsink" on page 40). Open the processor retaining latch and the processor socket retaining bracket. Using your fingers, remove the failed processor.
  • Page 57 All manuals and user guides at all-guides.com Disengage the power connector from the chassis. Retain the thumbscrews for future use. Remove the primary system board. To replace the system board: Install the spare system board in the server blade before installing the processor. Removal and replacement procedures 57...
  • Page 58 All manuals and user guides at all-guides.com Install the power connector onto the chassis. Prepare the processor socket on the spare system board: Remove the processor socket protective cover. Removal and replacement procedures 58...
  • Page 59 All manuals and user guides at all-guides.com Open the processor retaining latch and the processor socket retaining bracket. Install the processor socket cover onto the processor socket of the failed system board. Install the processor on the spare system board. CAUTION: The processor is designed to fit one way into the socket.
  • Page 60 All manuals and user guides at all-guides.com Close the processor retaining latch and the processor socket retaining bracket. Clean the old thermal grease from the heatsink and the top of the processor with the alcohol swab. Allow the alcohol to evaporate before continuing. Apply all the grease to the top of the processor in one of the following patterns to ensure even distribution: CAUTION:...
  • Page 61 All manuals and user guides at all-guides.com Install all components removed from the failed system board. Install the primary access panel. Install the secondary system board. Install the power connector onto the chassis. IMPORTANT: To maintain proper cooling, be sure the processor air baffle is installed at all times.

  • Page 62: Power Button/Led Board

    All manuals and user guides at all-guides.com Power button/LED board To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the secondary access panel ("Secondary access panel" on page 29). Remove the processor air baffle ("Processor air baffle"...

  • Page 63: Primary Front Bezel

    All manuals and user guides at all-guides.com Remove the secondary chassis. Remove the primary access panel ("Primary access panel" on page 29). Remove the power button/LED board cable ("Power button/LED board" on page 62). Remove the two T-5 screws and the power button/LED board. To replace the component, reverse the removal procedure.
  • Page 64 All manuals and user guides at all-guides.com Remove all DIMMs ("DIMMs" on page 35). Remove the FC mezzanine, if installed ("Fibre Channel mezzanine" on page 36). Remove the NIC mezzanine, if installed ("NIC mezzanine" on page 36). Remove the I/O signal board ("I/O signal board"...

  • Page 65: Secondary Front Bezel

    All manuals and user guides at all-guides.com Secondary front bezel To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the secondary access panel ("Secondary access panel" on page 29). Remove the secondary front bezel.

  • Page 66: Secondary Led Board

    All manuals and user guides at all-guides.com Remove the secondary LED board cable. To replace the component, reverse the removal procedure. Secondary LED board To remove the component: Power down the server blade (on page 28). Remove the server blade (on page 28). Remove the secondary access panel ("Secondary access panel"...

  • Page 67: Server Blade Bay Blank

    All manuals and user guides at all-guides.com Server blade bay blank Remove the server blade blank from the server blade enclosure. CAUTION: To prevent improper cooling and thermal damage, do not operate the server blade enclosure unless all bays are populated with either a component or a blank. To replace a server blade blank, align the blank with the empty bay and slide it in until the blank is fully seated.

  • Page 68: Diagnostic Tools

    To obtain the guide, refer to any of the following sources and then select the HP ProLiant Servers Troubleshooting Guide: •...

  • Page 69: Integrated Management Log

    For more information, refer to the Management CD in the HP ProLiant Essentials Foundation Pack. Array Diagnostic Utility The HP Array Diagnostics Utility is a web-based application that creates a report of all HP storage controllers and disk drives. This report provides vital information to assist in identifying faults or conditions that may require attention.

  • Page 70: Web-Based Enterprise Service

    For more information, refer to the HP website (http://h18000.www1.hp.com/support/svctools/). USB support HP provides both standard USB support and legacy USB support. Standard support is provided by the OS through the appropriate USB device drivers. Before the OS loads, HP provides support for USB devices through legacy USB support, which is enabled by default in the system ROM.

  • Page 71: Internal Usb Functionality

    All manuals and user guides at all-guides.com Internal USB functionality An internal USB connector is available for use with security key devices and USB drive keys. This solution provides for use of a permanent USB key installed in the internal connector, avoiding issues of clearance on the front of the rack and physical access to secure data.

  • Page 72: Server Component Identification

    All manuals and user guides at all-guides.com Server component identification Front panel LEDs Item LED description Status UID LED Blue = Identified Blue flashing = Active remote management Off = No active remote management Health LED Green = Normal Green flashing = Booting Amber flashing = Degraded condition Red flashing = Critical condition NIC 1*...

  • Page 73: Front Panel Components

    All manuals and user guides at all-guides.com Item LED description Status NIC 4* Green = Network linked Green flashing = Network activity Off = No link or activity NIC 5* Green = Network linked Green flashing = Network activity Off = No link or activity NIC 6* Green = Network linked Green flashing = Network activity...

  • Page 74: Rear Panel Components

    All manuals and user guides at all-guides.com Item Description Hard drive bay 2 * The I/O port is used with the local I/O cable to perform some server blade configuration and diagnostic procedures. Rear panel components Item Description Power connectors Signal connectors SAS and SATA hard drive LED combinations Online/activity...

  • Page 75: System Board Components

    All manuals and user guides at all-guides.com Online/activity Fault/UID LED Interpretation LED (green) (amber/blue) Flashing regularly Amber, flashing Do not remove the drive. Removing a drive may terminate the (1 Hz) regularly (1 Hz) current operation and cause data loss. The drive is part of an array that is undergoing capacity expansion or stripe migration, but a predictive failure alert has been received for this drive.

  • Page 76: Secondary System Board (Processors 2 And 4)

    All manuals and user guides at all-guides.com Item Description Power converter module FC mezzanine connectors (2) NIC mezzanine connector System maintenance switch (SW4) Processor 3 memory bank F Processor 3 memory bank E DIMM slots 9-12 Processor socket 3 (blank shown) Fan connectors (5) Front panel/LED board connector Processor socket 1 (populated)

  • Page 77: Dimm Slot Numbering

    All manuals and user guides at all-guides.com Item Description Processor 2 memory bank C DIMM slots 5-8 Processor socket 2 (populated) Fan connectors (5) Processor socket 4 (blank shown) DIMM slots 13-16 Processor 4 memory bank G Processor 4 memory bank H System board handles (2) FC mezzanine connectors (2) I/O signal board...

  • Page 78: System Maintenance Switch

    All manuals and user guides at all-guides.com Secondary system board DIMM slot numbering (processors 2 and 4) Item Description Memory bank DIMM slot 5 Processor 2 memory bank C DIMM slot 6 Processor 2 memory bank C DIMM slot 7 Processor 2 memory bank D DIMM slot 8 Processor 2 memory bank D...

  • Page 79: Internal Usb Connector

    All manuals and user guides at all-guides.com Internal USB connector For more information, see "Internal USB functionality (on page 71)." Local I/O cable Item Connector Description Local I/O For connecting to the local I/O port on the server blade front panel Video For connecting a video monitor USB 1...
  • Page 80 All manuals and user guides at all-guides.com Item Connector Description iLO RJ-45 For connecting an Ethernet to the server blade (10/100 Ethernet) iLO interface from a client device The local I/O cable ships with the enclosure. Server component identification 80...

  • Page 81: Cabling

    All manuals and user guides at all-guides.com Cabling Using the local I/O cable The local I/O cable enables the user to perform server blade administration, configuration, and diagnostic procedures in two ways: • Connecting locally to the server blade iLO 2 interface •...

  • Page 82: Connecting Locally To A Server Blade With Video And Usb Devices

    All manuals and user guides at all-guides.com Connect the local I/O cable to the I/O port on the server blade. CAUTION: Disconnect the local I/O cable when not in use. The port and connector do not provide a permanent connection. Rear iLO 2 connector performance degrades when the local I/O cable is connected, even if the iLO 2 connector on the cable is not in use.

  • Page 83: Accessing A Server Blade With Local Media Devices

    All manuals and user guides at all-guides.com CAUTION: Disconnect the local I/O cable when not in use. The port and connector do not provide a permanent connection. Rear iLO 2 connector performance degrades when the local I/O cable is connected, even if the iLO 2 connector on the cable is not in use. NOTE: For this configuration, a USB hub is not necessary.
  • Page 84 All manuals and user guides at all-guides.com USB CD-ROM drive USB keyboard USB mouse NOTE: Use a USB hub when connecting a USB diskette drive and/or USB CD-ROM drive to the server blade. The USB hub provides additional connections. Item Description Server blade Monitor...

  • Page 85: Specifications

    All manuals and user guides at all-guides.com Specifications Environmental specifications Specification Value Temperature range* Operating 10°C to 35°C (50°F to 95°F) Shipping -40°C to 60°C (-40°F to 140°F) Storage -20°C to 60°C (-4°F to 140°F) Maximum wet bulb temperature 30°C (86°F) Relative humidity (noncondensing)** Operating...

  • Page 86: Acronyms And Abbreviations

    All manuals and user guides at all-guides.com Acronyms and abbreviations BBWC battery-backed write cache Customer Self Repair DIMM dual inline memory module electrostatic discharge Fibre Channel host bus adapter HTTP hypertext transfer protocol input/output iLO 2 Integrated Lights-Out 2 Integrated Management Log ISEE Instant Support Enterprise Edition keyboard, video, and mouse...
  • Page 87 All manuals and user guides at all-guides.com light-emitting diode network interface controller OSEM Open Services Event Manager ProLiant Support Pack RBSU ROM-Based Setup Utility read-only memory serial attached SCSI SATA serial ATA Systems Insight Manager SMTP Simple Mail Transfer Protocol unit identification uninterruptible power system universal serial bus...

  • Page 88: Index

    16, 21 cache module 16, 21, 39, 75 HP Insight Diagnostics 68 cache module, removing 39 HP Instant Support Enterprise Edition 69 cautions 25 HP ProLiant Essentials Foundation Pack 69 component identification 72 HP Systems Insight Manager, overview 69...
  • Page 89 All manuals and user guides at all-guides.com LEDs, unit identification (UID) 72 secondary LED board cable 65 local I/O cable 16, 21, 79, 81 secondary system board 49 local I/O cable connector 79 serial connector 79 server blade bay blank 67 signal connector 74 Smart Array E200i Controller components 16, 21 management tools 68...
