Performance Index - HTI HT-03 Instruction Manual

Performance Index

Mode
Vanadium Oxide
Uncooled Infrared
Infrared detector type
Infrared resolution
Field angle
Cell size
NETD
Thermal imaging frame rate
Lens focal length
Emissivity setting
IFOV
Temperature measurement
resolution
Infrared response band
Focus mode
Temperature
measurement range
Measurement accuracy
Temperature measurement
mode
Color palette
Display size
11
HT-03 HT-03D
Vanadium Oxide
Uncooled Infrared
Focal Plane Focal Plane
120x90 80x60
26°×19° 17°×13°
12μm
≤50mK @25℃,@F/1.1
≤25Hz
3.2mm
Adjustable from 0.01 to 1.00
3.75mrad
0.1℃
8 to14μm
Free focus
-20℃ to +550℃(-4 ℉ to 1022 ℉)
±2℃(35.6℉) or ±2%
Center point/hot and cold spot tracking
Rainbow, iron, cold color, white hot,
black hot
2.8-inch(240×320)
Image display mode
Lighting system
Device storage
Storage Image/Video Format
Image/video export method
Menu language
Battery Type
Battery capacity
Working time
Power interface
Power configuration
Work temperature
Storage temperature
Relative humidity
Product weight
Product size
Infrared/visible light/dual light fusion
LED fill light
Built-in 4G eMMC (user available
storage space is about 3G)
JPG/MP4
USB connection to computer export
English、Chinese、Italian、German
Removable Rechargeable Lithium
Battery (18650)
2000mAh
2 to 3 hours
Micro USB
5 minutes / 20 minutes / no automatic
shutdown
-10℃ to +45℃ (14 ℉ to 122 ℉)
-20℃ to +60℃ (-4℉ to 140℉)
10% to 85%RH (non-condensing)
375g
96mm×72mm×226mm
12
