Thermal Imaging Camera
Instruction Manual
MENU
SELECT
ENTER
Dongguan Xintai Instrument Co.,Ltd.
Add: Building F, No. 13-16, Hongye Industrial Zone, Tangxia
community, Tangxia Town, Dongguan City
Postcode:523710
Tel:+86-769-82612006
Fax:+86-769-82612005
Website:www.hti-meter.com
www.hytechcn.com.cn www.xintest.en.alibaba.com
HT-18+
User Manual Version 1.0. August 11，2022.
Advertisement
Table of Contents
Related Manuals for HTI HT-18+
Summary of Contents for HTI HT-18+
- Page 1 Thermal Imaging Camera Instruction Manual MENU SELECT ENTER Dongguan Xintai Instrument Co.,Ltd. Add: Building F, No. 13-16, Hongye Industrial Zone, Tangxia community, Tangxia Town, Dongguan City Postcode:523710 Tel:+86-769-82612006 Fax:+86-769-82612005 Website:www.hti-meter.com www.hytechcn.com.cn www.xintest.en.alibaba.com HT-18+ User Manual Version 1.0. August 11，2022.
-
Page 2: Table Of Contents
Contents Preface 3."Video" sub-menu Limited warranty and limited responsibility 3.1. View video Safety instruction 3.2. Delete video Preliminary acquaintance with infrared thermal imager 4. Introduction to “color palette” sub-menu Overview 4.1. Color palette description Cleaning of the products 4.2. Application of color palette Lens maintenance 5. -
Page 3: Preface
Preface When warranty service is repaired, please contact the service center authorized by Xintai Instruments and Apparatus Co., Ltd to obtain the Respected users: authorization information for return. Then post the product together with How are you! Thank you for purchasing our instrument. In order to use it in problem description to the service center with postage and insurance a better manner, we remind you to read the instruction for use carefully expenses prepaid. -
Page 4: Safety Instruction
Safety instruction Warning Please ensure that you have read and understood the safety precautions The warning describes the acts that may cause harm to users. Please described in the following text before using the product so that you can observe the following operation in order to avoid electric shock or personal operate it correctly. - Page 5 Do not touch the electric wire with wet hands. Don’t weld the battery without permission. It is possible to cause electric shock when touching the electric wire Such operation may damage the battery and result in leakage and with wet hands. When pulling out the electric wire, hold the electric wire explosion of the battery.
-
Page 6: Preliminary Acquaintance With Infrared Thermal Imager
Preliminary acquaintance with infrared The product temperature may increase after a long time of thermal imager charging. You may feel scorching heat when the hands touch the sensors. For a long time, infrared thermal imaging detection technology has become an important means to ensure Industrial safety in developed countries. The Problem caused by water condensation. -
Page 7: Overview
Overview Cleaning of the products The outer shell of this product is cleaned with a damp cloth or diluted This product is an infrared camera that integrates surface temperature soapy liquid. Do not use abrasives, isopropanol or solvents for cleaning. measurement and real-time thermal image. -
Page 8: Charging Of The Battery And Description
Charging of the battery and description Battery Installation Use USB data line to charge: The product has built-in chargeable lithium batteries. When the battery level is low, the top right of the screen will display “ ”.Please charge in time through Micro USB interface（When the product is off, you can charge）. -
Page 9: Performance Index
Performance index Image display mode Infrared/visible light/dual light fusion Vanadium Oxide Uncooled Infrared Built-in 4G eMMC (user available Infrared detector type Device storage Focal Plane storage space is about 3G) Infrared resolution 256x192 Storage Image/Video Format JPG/MP4 Infrared response band 8 to14μm Image/video export method USB connection to computer export... -
Page 10: Product Description
Product description 1. Instruction to structure Please open the cap in use Visible light camera Display screen Infrared imaging sensor Keypad Image capture key Handheld Battery www.xintest.com.cn www.xintest.com.cn... -
Page 11: Display Description
2. Display description Temperature range Current emissivity Central point Battery power temperature Micro USB Color code Please open the cap in use The highest temperature cursor Temperature cursor at central point The lowest temperature Maximum cursor value/minimum value of field Time temperature Temperature range: The range of temperature measurement. -
Page 12: Key Description
LCD screen display The lowest temperature cursor: used to indicate the lowest temperature position in the screen area. It will move with the movement of the lowest After turning on the power, open the lens protection cover, as temperature. The cursor displays red. The temperature value is displayed shown in , the screen shows the thermal imaging status. -
Page 13: Introduction To The Menu
Introduction to the menu Record video Press the left of “ MENU ” key and the menu bar appears. They are “Image Long press the image capture button, the screen will prompt registration”, “Images”,“Videos”, “Color palette”, “Emissivity” and “Settings” “record video?”, if you select “Yes” at this time, please press the submenus. -
Page 14: Introduction To "Images" Sub-Menu
3."Video" sub-menu 2. Introduction to “images” sub-menu 3.1. View video 2.1. View image Press the “ MENU ” button to enter the main menu, and select “ ” Press the “ MENU ” button to enter the main menu, and select “ ”... -
Page 15: Introduction To "Color Palette" Sub-Menu
4. Introduction to “color palette” sub-menu 4.2. Application of color palette 4.1. Color palette description Color palette The palette can be used to change the pseudo-color display of the Spectra Iron infrared image on the display. Some tune Swatches are better Cool suited for specific applications and can be set up as needed. -
Page 16: Introduction To "Emissivity" Sub-Menu
5. Introduction to “emissivity” sub-menu 5.2. Emissivity setting The product is provided with four types of object measurement modes: 5.1. Emissivity description Matt (0.95) The emissivity of the product can be adjusted from 0.01 to 1.00 with the Semi-matt (0.85) default value of 0.95. -
Page 17: The Emissivity Value Of Common Materials
6. Introduction to “settings” sub-menu If you select "self-defined" emissivity, press the “ SELECT ” button to enter the editing state.Press “ ” / “ ” keys to select the Press “ MENU ” key to select the “ ”(settings) option in the main number to be changed, press “... -
Page 18: Auto Shutdown Setting
6.1. Auto shutdown setting 6.6. Time format setting After entering the "Settings" sub-menu, select “ ” (auto shutdown), After you select “ ”(time format), press the “ ” key in the press navigationThe “ ” button in the button enters the auto power navigation key to enter the time format setting. -
Page 19: Enable/Disable Of The Highest And Lowest Temperature Cursor
Thermal Imaging Image Analysis Software After the time setting is completed, press “ ” key to return. Press “ MENU ” exit from the menu. Operation Guide 6.8. Enable/disable of the highest and lowest Software Installation And Operation temperature cursor 1. - Page 20 Interface Introduction Icon Introduction 1. Select the language in the upper right corner of the interface, you can 1. " " icon, take the temperature of the thermal image. choose Chinese, English, and switch between the two languages. 2. On the right are shown as: fusion rate, color palette, temperature unit, 2.
-
Page 21: Troubleshooting
Troubleshooting If you encounter with any problem when using the thermal image device, please use the following table for repair.If the problems are not solved, please cut off the power supply and contact with the manufacturer. Failure phenomenon Failure cause Solution The battery is not Install the battery...
