Performance Index

Infrared detector type
Infrared resolution
Infrared response band
Cell size
NETD
Thermal imaging frame rate
Lens focal length
Emissivity setting
Field angle
Focus mode
Temperature
measurement range
Measurement accuracy
Temperature measurement
mode
Color palette
Display size
Image display mode
Lighting system
Device storage
11
Vanadium Oxide Uncooled Infrared
Focal Plane
256x192
8 to14μm
12μm
＜50mK @ F#1.0
≤25Hz
3.2mm
Adjustable from 0.01 to 1.00
35°×27°
Non-heating fixed focus lens
-20℃ to +550℃(-4 ℉ to 1022 ℉)
±2℃or ±2%
Center point/hot and cold spot tracking
Rainbow, iron, cold color, white hot,
black hot
2.8-inch(240×320)
Infrared/visible light/dual light fusion
LED fill light
Built-in 4G eMMC (user available
storage space is about 3G)
Storage Image/Video Format JPG/MP4
Image/video export method USB connection to computer export
Image analysis function Support offline analysis on PC
Menu language English、Chinese、Italian、German
Removable Rechargeable Lithium
Battery Type
Battery (18650)
Battery capacity 2000mAh
Working time 2 to 3 hours
Power interface Micro USB
5 minutes / 20 minutes / no automatic
Power configuration
shutdown
Work temperature 0℃ to +45℃ (32 ℉ to 113 ℉)
Storage temperature -20℃ to +60℃ (-4℉ to 140℉)
Relative humidity 10% to 85%RH (non-condensing)
Product weight 389g
Product size 96mm×72mm×226mm
